Xerox WorkCentre 3220 - Paper Empty Sensor

8-88 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Paper Empty Sensor
PL4.0.75
1. Remove tray 1.
2. Remove the Print Cartridge (page 8-8).
3. Remove the Duplex Unit (page 8-69).
4. Place the printer on its right side.
5. Remove 2 screws (12 mm, silver) that secure the duplex path frame.
s3210mfp-048
