WorkCentre 3210/3220 Multifunction Printer Service Manual 10-3
Wiring
Map 1 - Circuit Board Locator
A
11
12
13
14
15
16
17
18
19
20
21
22
23
24
10
BCDEFGHIJKL
s3210mfp-111
ADF Control Board
Power Supply
(SMPS)
HVPS
Main
Controller
Board
Control Board
ADF Interface Board
Fax Board
USB Board
