Xerox WorkCentre 3220 - Print Cartridge

8-8 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Print Cartridge
PL1.0.21
Caution
Do not touch the OPC drum or expose the Print Cartridge to light for more
than 5 minutes.
1. Open the front cover.
2. Push the Print Cartridge handle upward and pull the Print Cartridge out
from the printer.
s3210mfp-087
