3-20 WorkCentre 3210/3220 Multifunction Printer Service Manual
Error Messages and Codes
Install Toner
The Print Cartridge is not installed.
Applicable Error Message
■ Install Toner
Initial Actions
■ Clean the HVPS contacts on the Print Cartridge
■ Cycle printer power.
■ If problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Print Cartridge, PL1.0.21
■ HV ICT Shaft, PL4.0.6.1
■ HV Spring ETC, PL4.0.6.2
■ HVPS, PL1.0.3
■ Map 6 - HVPS
■ Power and Fuser
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat the Print Cartridge.
Does the error persist?
Go to step 2. Complete.
2 Clean the HVPS contacts on the Print
Cartridge and frame.
Does the error persist?
Go to step 3. Complete.
3 Replace the Print Cartridge.
Does the error persist?
Go to step 4. Complete.
4 Check the HV contacts located in the
frame behind the HVPS.
Are the contacts installed correctly and
is spring tension adequate?
Replace the
HVPS
(
page 8-101).
Repair the
contacts.

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
