Xerox WorkCentre 3220 Service Manual

10-2 WorkCentre 3210/3220 Multifunction Printer Service Manual
Wiring
Component Locator Diagrams
This chapter contains the plug/jack designators, component locator diagrams,
and wiring diagrams for the print engine, scanner, and ADF.
Component Locator
Maps 1 through 3 indicate the location of key components within the printer.
1. Map 1 - Circuit Board Locator
2. Map 2 - Drive Locator
3. Map 3 - Sensor Locator
Component Locator
Component Map Coordinates
ADF Control Board 1 D-14
Control Panel 1 B-16
Main Controller Board 1 I-17
Power Supply (SMPS) 1 H-19
HVPS 1 G-19
ADF Motor Assembly 2 E-33
Main Motor Assembly 2 C-38
Registration Clutch 2 B-39
Pick Up Solenoid 2 B-39
Scanner Motor 2 I-36
ADF Registration Sensor 3 D-73
ADF Exit Sensor 3 D-73
ADF No Paper Sensor 3 D-74
Interlock Switch 3 F-74
Output Tray Full Sensor 3 H-74
Exit Sensor 3 I-77
Rear Cover Interlock Switch 3 H-78
Front Cover Interlock Switch 3 G-79
Duplex Registration Sensor 3 F-79
Tray Feed Sensor 3 F-79
Tray No Paper Sensor 3 E-79
Laser Unit Fan 4 D-57
Main Fan 4 I-58
Power Supply Fan 4 H-60

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
