10-4 WorkCentre 3210/3220 Multifunction Printer Service Manual
Wiring
Map 2 - Drive Locator
A
31
32
33
34
35
36
37
38
39
40
41
42
43
44
30
BCDEFGHIJKL
s3210mfp-115
Registration Clutch
Pick Up Solenoid
Main Motor Assembly
ADF Motor Assembly
Scanner Motor
