Xerox WorkCentre 3220 Service Manual

3-18 WorkCentre 3210/3220 Multifunction Printer Service Manual
Error Messages and Codes
Out Bin Full
The Bin Full Sensor indicates the output tray is full.
Applicable Error Message
■ Out Bin Full
Initial Actions
■ Check the bin full actuator for damage or obstructions.
■ Cycle printer power.
■ If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Main Controller Board, PL1.0.2
■ Bin Full Actuator Holder, PL3.0.8
■ Bin Full Actuator, PL3.0.9
■ Bin Full Sensor, PL3.0.10
■ Map 3 - Sensor Locator
■ Main Controller Board
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the bin full actuator for damage.
Is the actuator damaged?
Repair the
actuator.
Go to step 2.
2 Check the connection between the
Main Controller Board CN12 and the
Bin Full Sensor.
Is the connection secure?
Go to step 3. Secure the
connections.
3 Check for +3.3 V at CN12-1.
Is +3.3 V present at CN12-1?.
Go to step 4. Replace the
Main Controller
Board
(page 8-100).
4 Check the continuity of the bin full
harness connecting the Main
Controller Board and Bin Full Sensor.
Is the harness damaged?
Repair the
harness.
Replace the Bin
Full Sensor
(page 8-70).

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
