WorkCentre 3210/3220 Multifunction Printer Service Manual 8-27
Service Parts Disassembly
Halogen Lamp
PL8.0.30
Warning
Allow the Fuser to cool before performing this procedure.
1. Remove the Fuser (page 8-13).
Caution
Do not apply too much pressure while releasing the tab to prevent damaging
the lamp cap.
2. Release the tab and remove the right lamp cap.
s3210mfp-028

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
