Xerox WorkCentre 3220 Service Manual

WorkCentre 3210/3220 Multifunction Printer Service Manual 4-23
General Troubleshooting
Power Supply Troubleshooting
Warning
Hazardous voltage is connected to the wall outlet.
AC Power Troubleshooting
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Power Supply, PL1.0.4 ■ Map 7 - Power Supply
■ Power and Fuser
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the voltage at the AC wall outlet.
Is there approximately 110 VAC (or
220
VAC if the printer is a 220 V
configuration) at the AC wall outlet?
Go to step 2. Notify the
customer of
improper AC
output from
the outlet.
2 Check the power cord for defects or loose
connection.
Is the Power Cord loose or defective?
Replace or
reconnect the
Power Cord.
Replace the
Power Supply
(
page 8-104).
