Xerox WorkCentre 3220 Service Manual

WorkCentre 3210/3220 Multifunction Printer Service Manual 5-39
Print-Quality Troubleshooting
Print-Quality Specifications
The Print-Quality specifications are as follows.
Skew
Vertical Skew
■ ±2.0 mm (Tray 1) / 241.3 mm
■ ±2.5 mm (Duplex, SCF) / 241.3 mm
■ ±3.5 mm (ADF) / 241.3 mm
Horizontal Skew
■ ±1.5 mm (Tray 1: ± 2.0 mm) / 177.8 mm
■ ±2.0 mm (Duplex, SCF) / 177.8 mm
■ ±2.5 mm (ADF) / 177.8 mm
Curl
For 20lb paper
■ 20 mm (0.79") Max, Environment: at NN condition with 5% page
coverage,
■ 30 mm (1.18") Max, Environment: at LL/HH condition with 5% page
coverage
For 24lb paper
■ 30 mm (1.18") Max, Environment: at all condition with 5% page coverage,
Measure the highest corner of 10 sheets of simplex output 5 minutes after
output on flat surface. Load the paper as indicated on the wrapper. If there is
no designation for proper paper up-side, test using both sides.
Registration
Left print position (scanning direction): ± 2.5mm (±3.0mm, Duplex)
Top print position (feeding direction): ± 3.0mm (±3.0mm, Duplex)
Noise
System noise specifications from different feed locations.
■ Printing (Tray 1): 50dB
■ Printing (Tray 2): 55dB
■ ADF: 53dB
■ Platen: 52dB

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
