Xerox WorkCentre 3220 Service Manual

WorkCentre 3210/3220 Multifunction Printer Service Manual 5-3
Print-Quality Troubleshooting
Fuser
■ Ghosting (3) (5-17)
■ Stains on the Back of the Page (5-26)
Print Cartridge
■ Light or Undertone Print (5-11)
■ Black Print (5-12)
■ Uneven Density (5-13)
■ Background Contamination (5-14)
■ Ghosting (2) (5-16)
■ Vertical White Line (5-18)
■ Vertical Black Line or Band (5-20)
■ Horizontal Black Line and Band (5-21)
■ Black/White Spot (5-22)
■ Stains on the Front of the Page (5-25)
■ Blank Page (1) (5-27)
■ Blank Page (2) (5-28)
ADF
Print quality problems related to the ADF generally come from two sources,
skew and banding. If image skew occurs when using the ADF, try using the
platen and repeat the copy. If the image is fine from the platen, but skews from
the ADF, examine the ADF rollers and ADF media path. Clean, and if
necessary replace the ADF Feeder Assembly and Feed Pad. Banding is often
the result of erratic ADF feed motion. In this case, clean the feed rollers and
validate the thickness of the original document. Any media out of specification
should be copied from the platen. If cleaning does not solve the problem,
replace the ADF feed components.

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
