8-14 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
5. Remove 4 screws (12 mm, silver) that secure the Fuser.
6. Pull the Fuser out from the printer.
110V
s3210mfp-025
