Xerox WorkCentre 3220 Service Manual

8-72 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Replacement Note
Be sure the D-shaped roller fits properly with the idle feed shaft.
Make sure the 2 mounting bosses are seated properly when installing the
Bracket. If the Bracket is not correctly installed, paper jam and grinding noise
will occur.
Be sure to secure the 3 screws in the order (1-3).
s3210mfp-214
s3210mfp-218
1
2
3

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
