Xerox WorkCentre 3220 Service Manual

9-12 WorkCentre 3210/3220 Multifunction Printer Service Manual
Parts List
Parts List 4.0 Frame
ID No. Name/Description Part Number
0. ELA HOU-Frame_110V
ELA HOU-Frame_220V
1. Frame-Base
2. Ground-Zenor
3. Zenor PBA 140N63401
4. PMO-Locker CST
5. Main Fan 127N07572
6.
6-1.
6-2.
HV Contact
ICT Shaft HV Large
Spring ETC-HV Large
7. Ground-Motor_Main
8. Ground-Controller
9. Ground-Paper
10. Ground-BRKT Front
11. Ground-Transfer
12. Holder-REGI
13. MEA Unit Swing
14. Gear Duplex RDCN
15. Collar Swing
16. BRKT Swing
17. Shaft-Feed REGI
18. Registration Clutch 121N01169
19. PMO-Bushing Feed
20. Roller-Feed REGI
21.
21-1.
21-2.
21-3.
Pick Up Gear
Gear Pick Up A
Spring-CS
Gear Pick Up B
130N01538
22. Cam-Pick Up
23. PMO-Idle Pick Up
24. Shaft-P-Pick Up
25. Stopper-M-Pick Up_R2
26.
26-1.
26-2.
26-3.
Pick Up Roll
Rubber Pick Up
Housing-M-Pick Up
Housing-M-Pick Up_R2
130N01540
27. Bush-M-Pick Up R2

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
