WorkCentre 3210/3220 Multifunction Printer Service Manual 9-21
Parts List
Parts List 6.1 ADF Assembly
ID No. Description Part Number
0. ADF
Platen Cover Hinge
022N02406
003N01051
3. Screw-Taptite
4. ADF Motor 127N07619
5. Lower ADF 022N02407
6. ADF Feeder Assembly 130N01500
7. Upper ADF 022N02408
8. MEA-Cover Open
9. Platen Cover 101N01441
10. MEA-TX Stacker
11. ADF Feed Pad Assembly 019N00928
12. ADF Rubber Feed Pad 019N00566
