WorkCentre 3210/3220 Multifunction Printer Service Manual 9-27
Parts List
Parts List 6.4 UI Assembly
ID No. Description Part Number
1. UI Assy (3220)
UI Assy (3210)
101N01438
101N01439
2. Cover-OPE (3220)
Cover OPE (3210)
3. Cover-Window SF-530
4. Screw-Taptite
5. Key-Extra
6. Key-FAX
7. Key-Menu
8. Key-OK
9. Key-Status
10. Key-Stop
11. Key-Tel
12. Key-Start
13. UI PBA 140N63396
14. Cover-LCD
