WorkCentre 3210/3220 Multifunction Printer Service Manual 9-33
Parts List
Parts List 9.0 Duplex Unit
ID No. Name/Description Part Number
0. Duplex Unit 022N02410
1. Frame Duplex Base
2. Terminal GND-DUP L
3. Terminal GND-DUP S
4. Bush M Feed, DUP
5. Roller Feed-DUP2
6. Ring-C
7. Pulley M-18 Dummy-DUP
8. Pulley 18-DUP
9. Gear Exit F/Down
10. Belt Timing Gear
11. Belt Timing Gear
12.
12-1.
12-2.
ELA Unit Roller-DUP
Roller Feed-DUP
Ring-C
13. Bracket Duplex-Align
14. Screw Tapping
15. Guide Duplex-Upper
16. Roller M-Idle-DUP
17. PCT-SILP Washer
18. Shaft Idle Roll, DUP
19. Spring-TS
20. Screw Taptite

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
