2-10 WorkCentre 3210/3220 Multifunction Printer Service Manual
Theory of Operation
ADF Feeder, Feed Pad, and Sensors
s3210mfp-237
ADF Rubber Feed Pad
ADF Feeder Assembly
2
ADF Exit Sensor
Registration Sensor
Empty Sensor
s3210mfp-245
