Xerox WorkCentre 5020 Service Documentation

July, 2007
2-17
WorkCentre 5020
Status Indicator RAPS
Initial Issue
E1-2
Error Name
Exit SNR on JAM
Explanation
Timeout between IOT Registration Clutch ON and Fuser Exit Sensor ON.
I/O Diagnostic Codes (How to Enter the Diagnostic Mode)
• [08-10] IOT Registration Clutch
• [10-23] Fuser Exit Sensor
Check Items
• Registration Roll dirty, contaminated with paper dust, worn, or faulty
• Fuser Exit Sensor dirty and Sensor Actuator deformed or damaged
• Paper damaged or not within specification
• Foreign matter, burrs, or paper in the paper path
• Drive gear worn or damaged
• IOT Registration Clutch faulty
• Check that the IOT Registration Clutch and the LVPS J503-4/5 ( P/J503) pins are connected securely with good electrical contact. If there is
no problem, replace the IOT Registration Clutch (PL 2.9).
• Check that the following wires are connected securely with good electrical contact. If there is no problem, replace the Fuser Exit Sensor (PL
6.2).
– Wire between Fuser Exit Sensor J153-3 ( P/J153) and LVPS J505-1 ( P/J505)
– Wire between Fuser Exit Sensor J153-2 and LVPS J505-2
– Wire between Fuser Exit Sensor J153-1 and LVPS J505-3
• Replace the AIOC PWB (PL 8.1) (REP 8.1.1).
O -
CH10.2
Figure 2
E3-1
Error Name
Exit SNR off JAM
Explanation
Timeout between Fuser Exit Sensor ON and Fuser Exit Sensor OFF.
I/O Diagnostic Codes (How to Enter the Diagnostic Mode)
[10-23] Fuser Exit Sensor
Check Items
• Fuser Exit Sensor dirty and Sensor Actuator deformed or damaged
• Paper damaged or not within specification
• Foreign matter, burrs, or paper in the paper path
• Drive gear worn or damaged
• Check that the following wires are connected securely with good electrical contact. If there is no problem, replace the Fuser Exit Sensor (PL
6.2).
– Wire between Fuser Exit Sensor J153-3 ( P/J153) and LVPS J505-1 ( P/J505)
– Wire between Fuser Exit Sensor J153-2 and LVPS J505-2
– Wire between Fuser Exit Sensor J153-1 and LVPS J505-3
• Replace the LVPS (PL 8.1) (REP 8.1.2) and the AIOC PWB (PL 8.1) (REP 8.1.1) in that order.
O -
CH10.2
Figure 2
Error
Code Error Name/Explanation/I/O Diagnostic Codes/Check Items
Record in
Error Log RAP BSD
