February, 2008
6-24
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
763-704 NVM_Book_Unstp_Eject_Exit_Speed_L 6 1~6 Exit speed of the Eject Motor for small size paper (paper length > 300 mm) during book-
let unstaple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-705 NVM_Bookstpl_Posshift_S 0 0~1 Stapler position shift for small-sized booklet staple job. 0: No shift, 1: Shift
763-706 NVM_Bookstpl_Posshift_L 0 0~1 Stapler position shift for large-sized (paper length > 330 mm) booklet staple job.
0: No shift, 1: Shift
763-707 NVM_Bookstpl_Posshift_Pls 57 27~170 1 pulse The amount of position shift (valid when NVM 763-705 or 763-706 = 1).
1 pulse = 0.1766 mm
763-710 Ex_Max_Booklet_Stapling 15 2~25 Maximum number of sheets at the binding fold in booklet staple mode.
763-711 NVM_Booklet_Full_Set_Count_S 50 1~255 Number of paper sets required for Booklet Full detection (standard = 15 pieces/set)
(paper length < B4S).
763-712 NVM_Booklet_Full_Set_Count_L 50 1~255 Number of paper sets required for Booklet Full detection (standard = 15 pieces/set)
(paper length = or > B4S).
763-713 Ex_Max_Booklet_Unstapling 5 1~15 Maximum number of sheets at the binding fold in booklet unstaple mode.
763-714 [Unused]
NVM_Booklet_Unstaple_Stack_Set_Count
100 1~255 [Unused] The maximum number of copies in a set allowed in the Stacker during booklet
unstaple mode.
763-715 NVM_Bklt_Mix_Full_Job_End_Chk_Setting 1 0~1 A limit of 1 job in booklet mode (staple or unstaple) when deciding a mixed-size stack.
0: No limit, 1: Limit
763-716 NVM_Bklt_Mix_Full_Job_Start_Chk_Setting 1 0~1 Immediately notice a mixed stack full condition when starting a mixed-size stack in
booklet mode.
0: Do not immediately notice, 1: Immediately notice
763-717 NVM_Bklt_Mix_Full_Job_End_Chk_Encoder_Cnt 6 1~255 Mix Full Detection Encoder position setting when a booklet job ends (booklet staple or
unstaple mode).
763-718 NVM_Tray_Full_Clear_Encoder_Cnt 6 1~255 Position at which Tray Encoder is cleared for Full, Mix Full, StackerTrayFull.
763-719 NVM_Encoder_Cnt_Tim 10 0~10 10 ms Increase the Encoder count time after the Stacker Tray Motor stops.
763-720 NVM_Book_Frnt_Nml_Tmp_Cnt 2 0~10 Normal tamping frequency of Front Tamper when booklet is ejected.
763-721 NVM_Book_Rear_Nml_Tmp_Cnt 2 0~10 Normal tamping frequency of Rear Tamper when booklet is ejected.
763-722 NVM_Book_Frnt_Set_Tmp_Cnt 6 0~10 Last tamping frequency of Front Tamper when booklet is ejected.
763-723 NVM_Book_Rear_Set_Tmp_Cnt 5 0~10 Last tamping frequency of Rear Tamper when booklet is ejected.
763-724 [Unused] NVM_Book_Eject_Exit_Speed_Mode 0 0~255 [Unused] Sets the eject output speed in booklet job mode.
763-725 NVM_Book_Size_Pos_Pls 17 0~33 Adjusts the pulse for Booklet Stapler Move size position.
Usage: pulse = 1230 + NVM_Book_Size_Pos_Pls - (Paper Width) / 0.3532.
763-726 NVM_Book_Trns_S_Adjust 52 0~90 Adjusts the pulse for the Eject Motor booklet transport operation when the booklet is
ejected (paper length < 364 mm [B4]).
Usage: pulse = 954.4 - (paper length)/0.495 + NVM_Book_Trns_S_Adjust.
NOTE: Increasing the value moves the staple position toward rear end of paper.
763-727 NVM_Book_Trns_L_Adjust 49 0~90 Adjusts the pulse for the Eject Motor booklet transport operation when the booklet is
ejected (paper length = or > 364 mm [B4]).
Usage: pulse = 954.4 - (paper length)/0.495 + NVM_Book_Trns_L_Adjust.
NOTE: Increasing the value moves the staple position toward rear end of paper.
763-728 NVM_Book_Tmp_Pls 12 0~24 Adjusts number of tamping pulses after booklet is ejected:
F Tamper = 32 + NVM_Book_Tmp_Pls
R Tamper = 51 - NVM_Book_Tmp_Pls
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
