WorkCentre 5225, 5230
IOT NVM List
General Procedures
Launch Version
763-688 Ex_Stacker_Staple_Count_Upper - 1, 2 Digit 0 0~99 Total staple frequency of Stacker (upper value).
Total staple frequency of Stacker = (upper value) x 65535 + (lower value).
763-688 Ex_Stacker_Staple_Count_Upper - 3, 4 Digit 0 0~99
763-688 Ex_Stacker_Staple_Count_Upper - 5, 6 Digit 0 0~6
763-689 Ex_Total_Punching_Counter_Lower - 1, 2 Digit 0 0~99 Total punch frequency (lower value)
Operation frequency of Punch Unit (lower value)
Total punch frequency = (upper value) x 65536 + (lower value)
763-689 Ex_Total_Punching_Counter_Lower - 3, 4 Digit 0 0~99
763-689 Ex_Total_Punching_Counter_Lower - 5, 6 Digit 0 0~6
763-690 Ex_Total_Punching_Counter_Upper - 1, 2 Digit 0 0~99 Total punch frequency (upper value)
Operation frequency of Punch Unit (upper value)
Total punch frequency = (upper value) x 65536 + (lower value)
763-690 Ex_Total_Punching_Counter_Upper - 3, 4 Digit 0 0~99
763-690 Ex_Total_Punching_Counter_Upper - 5, 6 Digit 0 0~6
763-691 Ex_Total_Sub_Pdl_Sol_Count_Lower - 1, 2 Digit 0 0~99 Sub Paddle Solenoid operating frequency (lower value).
Total operating frequency = (upper value) x 65535 + (lower value).
763-691 Ex_Total_Sub_Pdl_Sol_Count_Lower - 3, 4 Digit 0 0~99
763-691 Ex_Total_Sub_Pdl_Sol_Count_Lower - 5, 6 Digit 0 0~6
763-692 Ex_Total_Sub_Pdl_Sol_Count_Upper - 1, 2 Digit 0 0~99 Sub Paddle Solenoid operating frequency (upper value).
Total operating frequency = (upper value) x 65535 + (lower value).
763-692 Ex_Total_Sub_Pdl_Sol_Count_Upper - 3, 4 Digit 0 0~99
763-692 Ex_Total_Sub_Pdl_Sol_Count_Upper - 5, 6 Digit 0 0~6
763-693 Ex_Total_Set_Clamp_Count_Lower - 1, 2 Digit 0 0~99 Set Clamp operating frequency (lower value).
Total Set Clamp operating frequency = (upper value) x 65535 + (lower value).
763-693 Ex_Total_Set_Clamp_Count_Lower - 3, 4 Digit 0 0~99
763-693 Ex_Total_Set_Clamp_Count_Lower - 5, 6 Digit 0 0~6
763-694 Ex_Total_Set_Clamp_Count_Upper - 1, 2 Digit 0 0~99 Set Clamp operating frequency (upper value).
Total Set Clamp operating frequency = (upper value) x 65535 + (lower value).
763-694 Ex_Total_Set_Clamp_Count_Upper - 3, 4 Digit 0 0~99
763-694 Ex_Total_Set_Clamp_Count_Upper - 5, 6 Digit 0 0~6
763-695 Ex_Elevator_Mot_Up_Count_Lower - 1, 2 Digit 0 0~99 Elevator Motor UP operation frequency (lower value).
Total UP frequency of Elevator Motor = (upper value) x 65536 + (lower value).
763-695 Ex_Elevator_Mot_Up_Count_Lower - 3, 4 Digit 0 0~99
763-695 Ex_Elevator_Mot_Up_Count_Lower - 5, 6 Digit 0 0~6
763-696 Ex_Elevator_Mot_Up_Count_Upper - 1, 2 Digit 0 0~99 Elevator Motor UP operation frequency (upper value).
Total UP frequency of Elevator Motor = (upper value) x 65536 + (lower value).
763-696 Ex_Elevator_Mot_Up_Count_Upper - 3, 4 Digit 0 0~99
763-696 Ex_Elevator_Mot_Up_Count_Upper - 5, 6 Digit 0 0~6
763-697 Ex_Elevator_Mot_Down_Count_Lower - 1, 2 Digit 0 0~99 Elevator Motor DOWN operation frequency (lower value).
Total DOWN frequency of Elevator Motor = (upper value) x 65536 + (lower value).
763-697 Ex_Elevator_Mot_Down_Count_Lower - 3, 4 Digit 0 0~99
763-697 Ex_Elevator_Mot_Down_Count_Lower - 5, 6 Digit 0 0~6
763-698 Ex_Elevator_Mot_Down_Count_Upper - 1, 2 Digit 0 0~99 Elevator Motor DOWN operation frequency (upper value).
Total DOWN frequency of Elevator Motor = (upper value) x 65536 + (lower value).
763-698 Ex_Elevator_Mot_Down_Count_Upper - 3, 4 Digit 0 0~99
763-698 Ex_Elevator_Mot_Down_Count_Upper - 5, 6 Digit 0 0~6
763-699 NVM_Stacker_Tray_Position 0 0~150 Positional record of Stacker Tray (0 = uppermost position).
763-700 NVM_Booklet_Sub_CPU_Ver - 0~255 Booklet Sub CPU software version (for booklet control).
763-703 NVM_Book_Unstp_Eject_Exit_Speed_S 5 1~6 Exit speed of the Eject Motor for small size paper (paper length = or < 300 mm) during
booklet unstaple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
