Xerox WorkCentre 5225 Service Manual

February, 2008
6-22
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
763-672 Ex_Sheet_Width_Of_Last_Ejected_Sheet - 1, 2
Digit
0 0~99 Width of top sheet in Stacker Tray (0x0000~0xFFFF).
763-672 Ex_Sheet_Width_Of_Last_Ejected_Sheet - 3, 4
Digit
0 0~99
763-672 Ex_Sheet_Width_Of_Last_Ejected_Sheet - 5, 6
Digit
0 0~6
763-673 Ex_Sheet_Length_Of_Last_Ejected_Sheet - 1, 2
Digit
0 0~99 Length of top sheet in Stacker Tray (0x0000~0xFFFF).
763-673 Ex_Sheet_Length_Of_Last_Ejected_Sheet - 3, 4
Digit
0 0~99
763-673 Ex_Sheet_Length_Of_Last_Ejected_Sheet - 5, 6
Digit
0 0~6
763-674 Ex_Sheet_Width_Of_Maximum_Size_Sheet - 1, 2
Digit
0 0~99 Maximum width paper in Stacker Tray (0x0000~0xFFFF).
763-674 Ex_Sheet_Width_Of_Maximum_Size_Sheet - 3, 4
Digit
0 0~99
763-674 Ex_Sheet_Width_Of_Maximum_Size_Sheet - 5, 6
Digit
0 0~6
763-675 Ex_Sheet_Length_Of_Maximum_Size_Sheet - 1, 2
Digit
0 0~99 Maximum length paper in Stacker Tray (0x0000~0xFFFF).
763-675 Ex_Sheet_Length_Of_Maximum_Size_Sheet - 1, 2
Digit
0 0~99
763-675 Ex_Sheet_Length_Of_Maximum_Size_Sheet - 1, 2
Digit
0 0~6
763-677 Ex_Offset_Position 0 0~1 Final offset position. 0: Rear, 1: Front
763-679 NVM_Mix_Stack 0 0~1 Mix Full Stack detect. 0: Not detected, 1: Detected.
763-680 NVM_Puncher_Dust_Count - 1, 2 Digit 0 0~99 The number of sheets required to generate a Puncher Rubbish Full message.
763-680 NVM_Puncher_Dust_Count - 3, 4 Digit 0 0~99
763-680 NVM_Puncher_Dust_Count - 5, 6 Digit 0 0~6
763-684 NVM_Num_Of_Stack_Tray_Sheets - 1, 2 Digit 0 0~99 Number of output sheets for Full detection.
763-684 NVM_Num_Of_Stack_Tray_Sheets - 3, 4 Digit 0 0~99
763-684 NVM_Num_Of_Stack_Tray_Sheets - 5, 6 Digit 0 0~6
763-685 Ex_Stacker_Feed_Count_Lower - 1, 2 Digit 0 0~99 Number of Stacker output sheets (lower value).
Total number of sheets = (upper value) x 65535 + (lower value).
763-685 Ex_Stacker_Feed_Count_Lower - 3, 4 Digit 0 0~99
763-685 Ex_Stacker_Feed_Count_Lower - 5, 6 Digit 0 0~6
763-686 Ex_Stacker_Feed_Count_Upper - 1, 2 Digit 0 0~99 Number of Stacker output sheets (upper value).
Total number of sheets = (upper value) x 65535 + (lower value).
763-686 Ex_Stacker_Feed_Count_Upper - 3, 4 Digit 0 0~99
763-686 Ex_Stacker_Feed_Count_Upper - 5, 6 Digit 0 0~6
763-687 Ex_Stacker_Staple_Count_Lower - 1, 2 Digit 0 0~99 Total staple frequency of Stacker (lower value).
Total staple frequency of Stacker = (upper value) x 65535 + (lower value).
763-687 Ex_Stacker_Staple_Count_Lower - 3, 4 Digit 0 0~99
763-687 Ex_Stacker_Staple_Count_Lower - 5, 6 Digit 0 0~6
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
