Xerox WorkCentre 5225 Service Manual

February, 2008
6-21
WorkCentre 5225, 5230
IOT NVM List
General Procedures
Launch Version
763-652 NVM_Stk_Sml_Sub_Pdl_Sol_On_Tim - 1, 2 Digit 90 0~99 Change at Sub_Pdl_Sol_On_Time (Stack Job or Paper Length < 364.0 [B4] or the
amount by which the sheet set number exceeds the sheet switch number [NVM 763-
666]).
Usage: 100 + NVM_Stk_Sml_Sub_Pdl_Sol_On_Tim = On Time (initialize 190 ms).
763-652 NVM_Stk_Sml_Sub_Pdl_Sol_On_Tim - 3, 4 Digit 0 0~3
763-653 NVM_Stk_Sml_More_Sub_Pdl_Sol_On_Tim - 1, 2
Digit
50 0~99 Change at Sub_Pdl_Sol_On_Time (Stack Job or Paper Length >/= 364.0 [B4] or the
amount by which the sheet set number exceeds the sheet switch number [NVM 763-
666]).
Usage: 100 + NVM_Stk_Sml_More_Sub_Pdl_Sol_On_Tim = On Time (initialize 150
ms).
763-653 NVM_Stk_Sml_More_Sub_Pdl_Sol_On_Tim - 3, 4
Digit
0 0~3
763-654 NVM_Set_Clmp_Escape_Strt_Tim - 1, 2 Digit 50 0~0 1 ms Sets the time when the Set Clamp starts to go back and when the Clutch turns on.
Usage: 200 + NVM_Set_Clmp_Escape_Strt_Tim (initialize 400 ms).
763-654 NVM_Set_Clmp_Escape_Strt_Tim - 3, 4 Digit 2 0~4 1 ms
763-655 NVM_Set_Clmp_Escape_Keep_Tim 100 0~200 1 ms Sets the time when the Set Clamp Clutch turns on after the paper is exhausted.
Usage: 185 + NVM_Set_Clmp_Escape_Keep_Tim (initialize 285 ms).
763-656 NVM_Sub_Pdl_Sol_Pre_On_Tim 20 5~60 Time at which Sub Paddle Solenoid enters low noise operation.
763-657 NVM_Sub_Pdl_Sol_Pre_Off_Tim 25 5~60 Time at which Sub Paddle Solenoid exits from low noise operation.
763-658 NVM_Skew_Adjust_B4_More 50 10~255 1 ms Adjusts the amount of skew correction to the paper loop during a folding operation
(paper length > or = 364.0 [B4]).
763-659 NVM_Skew_Adjust_B4_Less 50 10~255 1 ms Adjusts the amount of skew correction to the paper loop during a folding operation
(paper length < 364.0 [B4]).
763-660 NVM_Skew_Adjust_Pulse_B4_More 20 0~255 1 pulse Allows the Transport Motor to perform a skew correction during a folding operation.
Adjusts the output pulse, from TransportEnt Snr On to start XportMot emergency stop
(paper length > or = 364.0 [B4]).
763-661 NVM_Skew_Adjust_Pulse_B4_Less 20 0~255 1 pulse Allows the Transport Motor to perform a skew correction during a folding operation.
Adjusts the output pulse, from TransportEnt Snr On to start XportMot emergency stop
(paper length < 364.0 [B4]).
763-662 NVM_Stk_Lrg_Less_Sub_Pdl_Sol_On_Tim - 1, 2
Digit
90 0~99 Change at Sub_Pdl_Sol_On_Time (Stack Job or Paper Length >/= 364.0 [B4] or the
amount by which the sheet set number exceeds the sheet switch number [NVM 763-
666]).
Usage: 100 + NVM_Stk_Lrg_Less_Sub_Pdl_Sol_On_Tim = On Time (initialize 190
ms).
763-662 NVM_Stk_Lrg_Less_Sub_Pdl_Sol_On_Tim - 3, 4
Digit
0 0~3
763-663 NVM_Stk_Lrg_More_Sub_Pdl_Sol_On_Tim - 1, 2
Digit
50 0~99 Change at Sub_Pdl_Sol_On_Time (Stack Job or Paper Length >/= 364.0 [B4] or the
amount by which the sheet set number exceeds the sheet switch number [NVM 763-
667]).
Usage: 100 + NVM_Stk_Lrg_More_Sub_Pdl_Sol_On_Tim = On Time (initialize 150
ms).
763-663 NVM_Stk_Lrg_More_Sub_Pdl_Sol_On_Tim - 3, 4
Digit
0 0~3
763-664 NVM_Front_Nml_Add_Tmp_Cnt 2 1~10 Number of additional tamps for a front, rear, or dual staple job.
763-665 NVM_Front_Set_Add_Tmp_Cnt 2 1~10 Number of additional tamps for a front, rear, or dual staple job.
763-666 NVM_Stk_Sml_Sub_Pdl_Sol_On_Papernum_B
Order
25 1~50 Sub_Pdl_Sol_On_Time (Stack Job or Paper Length < 364.0 [B4]) or the sheet switch
number
763-667 NVM_Stk_Sml_Sub_Pdl_Sol_On_Papernum_B
Order
25 1~50 Sub_Pdl_Sol_On_Time (Stack Job or Paper Length >/= 364.0 [B4]) or the sheet switch
number
763-671 NVM_Num_Of_Eject_Single_Staple_Set 0 0~255 Number of stapled copies outputted to the Stacker Tray.
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
