Xerox WorkCentre 5225 Service Manual

February, 2008
6-71
WorkCentre 5225, 5230
General Procedures
Launch Version
Chain 785-xxx IIT
780-166 Tray6 Medium Attribute 0 0~2 0: Not specified, 1: Paper for color copy, 2: Paper for B/W copy
780-167 Tray7 Medium Attribute 0 0~2 0: Not specified, 1: Paper for color copy, 2: Paper for B/W copy
780-170 Use Tray Paper Attr Color 1 0~1 0: Do not use, 1: Use
780-171 Use Tray Paper Attr Pre-Punched 0 0~1 0: Do not use, 1: Use
780-172 Tray 1 Medium Pre-Punched 1 1~2 1: Paper with no pre-punched holes, 2: Paper with pre-punched holes (number/position of
holes is disregarded)
780-173 Tray 2 Medium Pre-Punched 1 1~2 1: Paper with no pre-punched holes, 2: Paper with pre-punched holes (number/position of
holes is disregarded)
780-174 Tray 3 Medium Pre-Punched 1 1~2 1: Paper with no pre-punched holes, 2: Paper with pre-punched holes (number/position of
holes is disregarded)
780-175 Tray 4 Medium Pre-Punched 1 1~2 1: Paper with no pre-punched holes, 2: Paper with pre-punched holes (number/position of
holes is disregarded)
780-176 Tray 5 Medium Pre-Punched 1 1~2 1: Paper with no pre-punched holes, 2: Paper with pre-punched holes (number/position of
holes is disregarded)
780-177 Tray 6 Medium Pre-Punched 1 1~2 1: Paper with no pre-punched holes, 2: Paper with pre-punched holes (number/position of
holes is disregarded)
780-178 Tray 7 Medium Pre-Punched 1 1~2 1: Paper with no pre-punched holes, 2: Paper with pre-punched holes (number/position of
holes is disregarded)
780-192 Image Quality Control Category: Cort 0~60 -
780-193 Image Quality Control Category: Cort Rev 0~60 -
780-196 IOT Oottray OCT Enable - 0~1 0: Not provided (automatic detection), 1: Provided
780-203 Tray 1 Fixed Medium Direction 0 0~2 0: Not specified, 1: LEF, 2: SEF
780-204 Tray 1 Fixed Medium Size 0 0~255 0: Not specified
780-205 Tray 2 Fixed Medium Direction 0 0~2 0: Not specified, 1: LEF, 2: SEF
780-206 Tray 2 Fixed Medium Size 0 0~255 0: Not specified
780-207 Tray 3 Fixed Medium Direction 0 0~2 0: Not specified, 1: LEF, 2: SEF
780-208 Tray 3 Fixed Medium Size 0 0~255 0: Not specified
780-209 Tray 4 Fixed Medium Direction 0 0~2 0: Not specified, 1: LEF, 2: SEF
780-210 Tray 4 Fixed Medium Size 0 0~255 0: Not specified
780-211 Tray 6 Fixed Medium Direction 0 0~2 0: Not specified, 1: LEF, 2: SEF
780-212 Tray 6 Fixed Medium Size 0 0~255 0: Not specified
780-213 Tray 7 Fixed Medium Direction 0 0~2 0: Not specified, 1: LEF, 2: SEF
780-214 Tray 7 Fixed Medium Size 0 0~255 0: Not specified
780-215 HCS Tray Offset Enable 1 1~3 1: Per set, 2: Per job, 3: No offset
Table 7 IOT
Chain-
Link Content Default Range Meaning
Table 8 IIT
Chain-
Link
Content Default Range Meaning
785-003 Image Processing Method of FAX Photo Error Diffusion 0~1 0: Error Diffusion (1bit, ED), 1: Dither
