Page #1213 background image
February, 2008
6-74
WorkCentre 5225, 5230
Launch Version
General Procedures
790-070 Default Tray in Copy 0 0~7 0: Auto, 1: Tray 1, 2: Tray 2, 3: Tray 3, 4: Tray 4, 5: MPT, 6: Tray 6 (HCF), 7: Tray 7
(HCF). Refer to the Copy Service Func FF for the setting range.
790-071 Default Tray on Release ATS in Copy 1 1~7 1: Tray 1, 2: Tray 2, 3: Tray 3, 4: Tray 4, 5: MPT, 6: Tray 6 (HCF), 7: Tray 7 (HCF).
Refer to the Copy Service Func FF for the setting range.
790-072 Default Reduce/Enlarge in Copy 0 0~255 0:100% 1~12: R/E Preset 1 ~ R/E Preset 12 255: Auto
790-073 Fixed Reduce/Enlarge 1 in Copy XE/DMO-E: 1001 (25%), DMO-W:
1003 (50%), XC:1001 (25%)
25~1026 1~24: Not in use, 25~400:%, 401~1000: Not in use, 1001: 25.00%, 1002: 35.30%,
1003: 50.00%, 1004: 57.70%, 1005: 61.20%, 1006:64.70%, 1007: 70.70%, 1008:
78.50%, 1009: 81.60%, 1010: 86.60%, 1011: 94.00%, 1012: 97.30%, 1013:
115.40%, 1014: 122.50%, 1015: 127.30%, 1016: 129.40%, 1017: 141.40%, 1018:
154.50%, 1019: 163.20%, 1020: 173.20%, 1021: 180.00%, 1022: 200.00%, 1023:
220.00%, 1024: 282.80%, 1025: 400.00%, 1026: 300.00%
790-074 Fixed Reduce/Enlarge 2 in Copy XE/DMO-E: 1003(50%), DMO-W:
1006 (64.7%), XC:1003(50%)
1001~1026 1~1000: Not in use, 1001: 25.00%, 1002: 35.30%, 1003: 50.00%, 1004: 57.70%,
1005: 61.20%, 1006: 64.70%, 1007: 70.70%, 1008: 78.50%, 1009: 81.60%, 1010:
86.60%, 1011: 94.00%, 1012: 97.30%, 1013: 115.40%, 1014: 122.50%, 1015:
127.30%, 1016: 129.40%, 1017: 141.40%, 1018: 154.50%, 1019: 163.20%, 1020:
173.20%, 1021: 180.00%, 1022: 200.00%, 1023: 220.00%, 1024: 282.80%, 1025:
400.00%, 1026: 300.00%
790-075 Fixed Reduce/Enlarge 3 in Copy XE/DMO-E: 1007(70.7%), DMO-W:
1007 (70.7%), XC:1006(64.7%)
1001~1026 Same as above
790-076 Fixed Reduce/Enlarge 4 in Copy XE/DMO-E: 1012(97.3%), DMO-W:
1008 (78.5%), XC:1008(78.5%)
1001~1026 Same as above
790-077 Fixed Reduce/Enlarge 5 in Copy XE/DMO-E: 1017(141.4%), DMO-W:
1012 (97.3%), XC:1016(129.4%)
1001~1026 Same as above
790-078 Fixed Reduce/Enlarge 6 in Copy XE/DMO-E: 1022(200%), DMO-W:
1017 (141.4%), XC:1025(400%)
1001~1026 Same as above
790-079 Fixed Reduce/Enlarge 7 in Copy XE/DMO-E: 1025(400%), DMO-W:
1017 (141.4%), XC:1025(400%)
1001~1026 Same as above
790-085 EWB - Site Scan Warn 0 0~1 0: Do not give warning regarding the availability of protection at the time of moving
to a different website, 1: Give warning
790-086 EWB - Redirect 2 0~2 0: Do not give warning when redirected at the time of form transmission, 1: Give
warning, 2: Give warning when redirected to a different host
790-087 EWB - Cert Valid 1 0~1 0: Stop temporary access to unreliable server, 1: Ask user
790-088 Display Logout Confirm Popup 0 0~1 0: Do not display, 1: Display
790-094 Default BW Original Type in Copy 1 1~4 1: Text, 2: Text & Photo, 3: Photo, 4: Pencil Text
790-097 Default Background Suppression in Copy 1 0~1 0: Off, 1: On
790-098 Default Density Adjustment in Copy 3 0~6 0: Lighter 3, 1: Lighter 2, 2: Lighter 1, 3: Normal, 4: Darker 1, 5: Darker 2, 6: Darker 3
790-099 Mixed Size Default 0 0~1 0: Off, 1: On
790-122 Default Sharpness in Copy 2 0~4 0: Sharper, 1: Sharp, 2: Normal, 3: Soft, 4: Softer
790-124 Default Center / Corner Shift Position
(Side1)
0 0~9 0: No shift, 1: Center, 2: Top Right, 3: Bottom Right, 4: Top Left, 5: Bottom Left, 6:
Top Center, 7: Bottom Center, 8: Left Center, 9: Right Center
790-125 Default Center / Corner Shift Position
(Side2)
10 0~10 0: No shift, 1: Center, 2: Top Right, 3: Bottom Right, 4: Top Left, 5: Bottom Left, 6:
Top Center, 7: Bottom Center, 8: Left Center, 9: Right Center, 10: Opposite to Side 1
Table 9 UI
Chain-
Link Content Default Range Meaning
