Xerox WorkCentre 5225 Service Manual

February, 2008
6-75
WorkCentre 5225, 5230
General Procedures
Launch Version
790-126 FAX Broadcast 0 0~2 0: Broadcast prohibited, 1: Broadcast permitted (re-entry not required), 2: Broadcast
permitted (re-entry required)
790-127 FAX Second Input Method 0 0~2 0: Speed dial, 1: Full dial, 2: No input for the second time
790-128 Center Erase in Copy 0 (mm) 0~50 0 (mm) ~ 50 (mm) in 1mm increments
790-129 Rotation Enable in Copy 1 0~2 0: Always ON 1: ON only for APS/AMS 2: Always OFF
790-130 Default of Direction of Image Finisher models: 0, No Finisher: 1 0~2 0: Auto, 1: Portrait Original - Left Edge, 2: Portrait Original - Right Edge
790-131 Fixed Original Size 1 in Copy XE/DMO-E: 10 (A3S), DMO-W: 10
(A3S), XC: 89 (8.5x11L)
2~255 1: Not defined, 10: A3SEF, 11: A4LEF, 12:A4SEF, 13: A5LEF, 14: A5SEF, 15:
A6LEF, 16: A6SEF, 50: C4 Envelope SEF, 51: C5 Envelope SEF, 55: DL Envelope
LEF, 66: B4SEF, 67: B5LEF, 68: B5SEF, 69: B6LEF, 70: B6SEF, 80: 11x17SEF, 87:
PostcardLEF, 88: PostcardSEF, 89: 8.5x11LEF, 90: 8.5x11SEF, 92: 8.5x14SEF, 94:
12x18SEF, 98: 12x19SEF, 101: 16K LEF, 102: 16K SEF, 104: 8K SEF, 105: Post
-
card (3.5x5.5) LEF, 106: Postcard (3.5x5.5) SEF, 107: Postcard (4x6) LEF, 108:
Postcard (4x6) SEF, 109: Postcard (5x7) LEF, 110: Postcard (5x7) SEF, 111:
5.5x8.5LEF, 112: 5.5x8.5SEF, 113: Postcard (6x9) LEF, 114: Postcard (6x9) SEF,
115: 8x10LEF, 116: 8x10SEF, 118: 8.5x13SEF, 119: 7.25x10.5LEF, 120:
7.25x10.5SEF, 123: Youkei 0 LEF, 124: Choukei 3 SEF, 126: Choukei 4 SEF, 132:
11x15SEF, 135: Photo L LEF, 136: Photo L SEF, 137: Commercial 10 LEF, 139:
215x315mm (8.46x12.4) SEF, 141: SRA3 SEF, 142: Special A3SEF, 143: Special
A4LEF, 144: Special A4SEF, 145: A4 Cover SEF, 146: A4 Cover LEF, 147:
13x19SEF, 148: 13x18SEF, 149: 12.6x19.2SEF, 150: Letter Cover (9x11) SEF, 151:
Letter Cover (9x11) LEF, 152: Monarch Envelope LEF, 154: Prepaid Postcard LEF,
155: Prepaid Postcard SEF, 156: 16K LEF (GCO), 157: 16K SEF (GCO), 159: 8K
SEF (GCO)
790-132 Fixed Original Size 2 in Copy XE/DMO-E: 12 (A4SEF), DMO-W: 12
(A4SEF), XC: 90 (8.5x11SEF)
1~255 Same as above
790-133 Fixed Original Size 3 in Copy XE/DMO-E: 11 (A4LEF), DMO-W: 11
(A4LEF), XC: 92 (8.5x14SEF)
1~255 Same as above
790-134 Fixed Original Size 4 in Copy XE/DMO-E: 14 (A5SEF), DMO-W: 14
(A5SEF), XC: 80 (11x17SEF)
1~255 Same as above
790-135 Fixed Original Size 5 in Copy XE/DMO-E: 16 (A6SEF), DMO-W: 16
(A6SEF), XC: 112 (5.5x8.5SEF)
1~255 Same as above
790-136 Fixed Original Size 6 in Copy XE/DMO-E: 66 (B4SEF), DMO-W: 66
(B4SEF), XC:120 (7.25x10.5SEF)
1~255 Same as above
790-137 Fixed Original Size 7 in Copy XE/DMO-E: 68 (B5SEF), DMO-W: 68
(B5SEF), XC:110 (5x7SEF)
1~255 Same as above
790-138 Fixed Original Size 8 in Copy XE/DMO-E: 67 (B5LEF), DMO-W: 67
(B5LEF), XC:107 (4x6SEF)
1~255 Same as above
790-139 Fixed Original Size 9 in Copy XE/DMO-E: 80 (11x17SEF), DMO-W:
92 (8.5x14SEF), XC:12 (A4SEF)
1~255 Same as above
790-140 Fixed Original Size 10 in Copy XE/DMO-E: 118 (8.5x13SEF), DMO-
W: 118 (8.5x13SEF), XC:11 (A4LEF)
1~255 Same as above
790-141 Fixed Original Size 11 in Copy XE/DMO-E: 89 (8.5x11LEF), DMO-W:
89 (8.5x11LEF), XC:10 (A3SEF)
1~255 Same as above
790-148 Action Type of Select List Item in JFS 1 0~1 0: Select list, 1: Open detail/setting screen
Table 9 UI
Chain-
Link Content Default Range Meaning
