Page #1215 background imageLoading...
Page #1215 background image
February, 2008
6-76
WorkCentre 5225, 5230
Launch Version
General Procedures
790-149 Max Copy Volume 999 1~9999 1 to 9999 sheets
790-172 Paper Type for Copy APS 0 0~255 0: Conform to conventional priority sequence. Note: Types of paper, other than
tabbed sheet, that can be set to Trays other than SMH and Interposer can be speci
-
fied.
790-173 Paper Color for Copy APS 1 0~21 0: All paper colors, 1: White, 2: Pink, 3: Yellow, 4: Ocher, 5: Gold, 6: Blue, 7: Green,
8: Transparent, 10: Red, 13: Other, 14: Cream, 15: Gray, 16: Orange, 17: User-
defined color 1, 18: User-defined color 2, 19: User-defined color 3, 20: User-defined
color 4, 21: User-defined color 5
790-175 Box Service Print Order 0 0~3 0: In the ascending order of document registration time and date, 1: In the descend-
ing order of document registration time and date
790-180 Default of Right Image direction 0 0~1 0: Head to Top, 1: Head to Left
790-181 Default Duplex Setting 0 0~3 0: None (1->1 Sided), 1: 1->2 Sided, 2: 2->1 Sided, 3: 2->2 Sided
790-182 Default Sort Mode in Copy 0 0~3 0: Auto, 1: Collate, 2: Uncollated, 3: Uncollated with separator insertion
790-183 Default Exit Tray in Copy Out of the installed destination Trays,
the destination Tray is determined
based on the following priority order:
1) 0: Center Tray (Center Tray 1)
2) 3: Center Tray 2
3) 5: HCS1 Top Tray
4) 4: Top Tray
5) 2: Finisher Tray
0~8 0: Center Tray, 1: Side Tray, 2: Finisher Tray, 3: Center Tray 2, 4: Top Tray, 5: HCS1
Top Tray, 6: HCS1 Stacker Tray, 7: HCS2 Top Tray, 8: HCS2 Stacker Tray
*Options cannot be selected if they are not installed
790-184 Sending Display Enable 0 0~1 0: Off 1: On
790-185 Initial Display of Address 0 0~4 0: Off 1: On 2: Destination address screen 3: Basic screen 4: Address book
790-186 Default Communication Mode in FAX 2 0~6 1: G4 Auto, 2: G3 Auto, 3: F4800 (Communication speeds below 4800bps) The fol-
lowing are additional settings for M/N: 4: G3 5: G3 (ECM) 6: G3 (ECM)? Forced4800
790-187 Default Scanning Density in FAX 3 0~6 0: Lighter 3, 1: Lighter 2, 2: Lighter 1, 3: Normal, 4: Darker 1, 5: Darker 2, 6: Darker 3
790-188 Default Original Type in FAX 0 0~2 0=Text, 1=Photo, 2=Text & Photo
790-189 Default Scanning Resolution in FAX 0 0~3 0: Standard, 1: Fine (200x200), 2: Fine (400x400), 3: Fine (600x600)
790-190 FAX Monitor Print Enable 0 0~1 0: Off 1: On
790-191 Default Subject of Internet Fax Null 128 bytes maximum, null-terminated
790-192 Send Header Enable 1 0~1 0: Off 1: On
790-193 Destination Table in FAX 1 1~999999 1~999999
790-194 Mix Size Enable in FAX 0 0~1 0: Off 1: On
790-195 FAX Receive Mode 0 0~1 0: Auto Receive, 1: Manual Receive
790-196 Delayed Send Time Setting-hour 21 0~23 Hour (0~23) (24-hour clock)
790-197 Delayed Send Time Setting-minutes 0 0~59 Minute (0~59)
790-198 FAX Manual Send Receive 1 0~1 0: Manual Receive, 1: Manual Send
790-200 Fixed Reduce/Enlarge 1 in FAX XE/DMO-E: 1003 (50%), DMO-W:
1003 (50%), XC: 1003 (50%)
50~1026 1~49: Not in use, 50~400%, 401~1000: Not in use, 1001: 25.00%, 1002: 35.30%,
1003: 50.00%, 1004: 57.70%, 1005: 61.20%, 1006: 64.70%, 1007: 70.70%, 1008:
78.50%, 1009: 81.60%, 1010: 86.60%, 1011: 94.00%, 1012: 97.30%, 1013:
115.40%, 1014: 122.50%, 1015: 127.30%, 1016: 129.40%, 1017: 141.40%, 1018:
154.50%, 1019: 163.20%, 1020: 173.20%, 1021: 180.00%, 1022: 200.00%, 1023:
220.00%, 1024: 282.80%, 1025: 400.00%, 1026: 300.00%
Table 9 UI
