Xerox WorkCentre 5225 Service Manual

February, 2008
6-77
WorkCentre 5225, 5230
General Procedures
Launch Version
790-201 Fixed Reduce/Enlarge 2 in FAX XE/DMO-E: 1007 (70.7%), DMO-W:
1006 (64.7%), XC: 1006 (64.7%)
50~1026 Same as above
790-202 Fixed Reduce/Enlarge 3 in FAX XE/DMO-E: 1009 (81.6%), DMO-W:
1007 (70.7%), XC: 1008 (78.5%)
50~1026 Same as above
790-203 Fixed Reduce/Enlarge 4 in FAX XE/DMO-E: 1012 (97.3%), DMO-W:
1008 (78.5%), XC: 1012 (97.3%)
50~1026 Same as above
790-204 Fixed Reduce/Enlarge 5 in FAX XE/DMO-E: 1017 (141.4%), DMO-W:
1012 (97.3%), XC: 1016 (129.4%)
50~1026 Same as above
790-205 Fixed Reduce/Enlarge 6 in FAX XE/DMO-E: 1022 (200%), DMO-W:
1016 (129.4%), XC: 1023 (220%)
50~1026 Same as above
790-206 Fixed Reduce/Enlarge 7 in FAX XE/DMO-E: 1025 (400%), DMO-W:
1017 (141.4%), XC: 1025 (400%)
50~1026 Same as above
790-207 Add Sender to Address 0 0~1 0: Do not add, 1: Add
790-208 Add Sender to CC 0 0~1 0: Do not add, 1: Add
790-209 Modify Address 1 0~1 0: Prohibited, 1: Permitted
790-210 Fixed Original Size 1 in FAX Scan XE/DMO-E: 10 (A3SEF), DMO-W: 10
(A3SEF), XC: 89 (8.5x11LEF)
0~255 1: Not defined, 10: A3SEF, 11: A4LEF, 12:A4SEF, 13: A5LEF, 14: A5SEF, 15:
A6LEF, 16: A6SEF, 50: C4 Envelope SEF, 51: C5 Envelope SEF, 55: DL Envelope
LEF, 66: B4SEF, 67: B5LEF, 68: B5SEF, 69: B6LEF, 70: B6SEF, 80: 11x17SEF, 87:
PostcardLEF, 88: PostcardSEF, 89: 8.5x11LEF, 90: 8.5x11SEF, 92: 8.5x14SEF, 94:
12x18SEF, 98: 12x19SEF, 101: 16K LEF, 102: 16K SEF, 104: 8K SEF, 105: Post
-
card (3.5x5.5) LEF, 106: Postcard (3.5x5.5) SEF, 107: Postcard (4x6) LEF, 108:
Postcard (4x6) SEF, 109: Postcard (5x7) LEF, 110: Postcard (5x7) SEF, 111:
5.5x8.5LEF, 112: 5.5x8.5SEF, 113: Postcard (6x9) LEF, 114: Postcard (6x9) SEF,
115: 8x10LEF, 116: 8x10SEF, 118: 8.5x13SEF, 119: 7.25x10.5LEF, 120:
7.25x10.5SEF, 123: Youkei 0 LEF, 124: Choukei 3 SEF, 126: Choukei 4 SEF, 132:
11x15SEF, 135: Photo L LEF, 136: Photo L SEF, 137: Commercial 10 LEF, 139:
215x315mm (8.46x12.4) SEF, 141: SRA3 SEF, 142: Special A3SEF, 143: Special
A4LEF, 144: Special A4SEF, 145: A4 Cover SEF, 146: A4 Cover LEF, 147:
13x19SEF, 148: 13x18SEF, 149: 12.6x19.2SEF, 150: Letter Cover (9x11) SEF, 151:
Letter Cover (9x11) LEF, 152: Monarch Envelope LEF, 154: Prepaid Postcard LEF,
155: Prepaid Postcard SEF, 156: 16K LEF (GCO), 157: 16K SEF (GCO), 159: 8K
SEF (GCO)
790-211 Fixed Original Size 2 in FAX Scan XE/DMO-E: 12 (A4SEF), DMO-W: 12
(A4SEF), XC: 90 (8.5x11SEF)
0~255 Same as above
790-212 Fixed Original Size 3 in FAX Scan XE/DMO-E: 11 (A4LEF), DMO-W: 11
(A4LEF), XC: 92 (8.5x14SEF)
0~255 Same as above
790-213 Fixed Original Size 4 in FAX Scan XE/DMO-E: 14 (A5SEF), DMO-W: 14
(A5SEF), XC: 80 (11x17SEF)
0~255 Same as above
790-214 Fixed Original Size 5 in FAX Scan XE/DMO-E: 16 (A6SEF), DMO-W: 16
(A6SEF), XC: 112 (5.5x8.5SEF)
0~255 Same as above
790-215 Fixed Original Size 6 in FAX Scan XE/DMO-E: 66 (B4SEF), DMO-W: 66
(B4SEF), XC: 120 (7.25x10.5SEF)
0~255 Same as above
790-216 Fixed Original Size 7 in FAX Scan XE/DMO-E: 68 (B5SEF), DMO-W: 68
(B5SEF), XC: 109 (5x7LEF)
0~255 Same as above
Table 9 UI
Chain-
Link Content Default Range Meaning

Xerox WorkCentre 5225 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Internal memory	No MB
Type	Digital copier
