Xerox WorkCentre 5225 Service Manual

February, 2008
6-78
WorkCentre 5225, 5230
Launch Version
General Procedures
790-217 Fixed Original Size 8 in FAX Scan XE/DMO-E: 67 (B5LEF), DMO-W: 67
(B5LEF), XC: 107 (4x6LEF)
0~255 Same as above
790-218 Fixed Original Size 9 in FAX Scan XE/DMO-E: 80 (11x17SEF), DMO-W:
92 (8.5x14SEF), XC: 12 (A4SEF)
0~255 Same as above
790-219 Fixed Original Size 10 in FAX Scan XE/DMO-E: 118 (8.5x13SEF), DMO-
W: 118 (8.5x13SEF), XC: 11 (A4LEF)
0~255 Same as above
790-220 Fixed Original Size 11 in FAX Scan XE/DMO-E: 89 (8.5x11LEF), DMO-W:
89 (8.5x11LEF), XC: 10 (A3SEF)
0~255 Same as above
790-221 iFAX Profile 0 0~2 [0: TIFF-S, 1: TIFF-F, 2: TIFF-J]
790-222 Mix Size Enable in Scan 0 0~1 0: Off 1: On
790-223 Default Color Mode in Scan 2 0~3 0: Full Color, 1: Grayscale, 2: Dual Color, 3: Auto
790-224 Default Original Type in Scan 0 0~2 0: Text, 1: Photo, 2: Text & Photo
790-225 Default Scanning Resolution in Scan 0 0~4 0: 200dpi, 1: 300dpi, 2: 400dpi, 3: 600dpi, 4: Refer to Scan FF (Input Common) for
the setting range.
790-226 Top & Bottom Edge Erase in Scan 2 (mm) 0~50 0 (mm) ~ 50 (mm) in 1mm increments
790-227 Left & Right Edge Erase in Scan 2 (mm) 0~50 0 (mm) ~ 50 (mm) in 1mm increments
790-228 Center Erase in Scan 0 (mm) 0~50 0 (mm) ~ 50 (mm) in 1mm increments
790-229 Density / Brightness Adjust in Scan 3 0~6 0: Brightness (Density) 3, 1 Brightness (Density) 2, 2 Brightness (Density) 1, 3 Stan-
dard, 4: Brightness (Density) -1, 5 Brightness (Density) -2, 6 Brightness (Density) -3
790-230 Contrast Adjust in Scan 2 0~4 0: Higher, 1: High, 2: Standard, 3: Low, 4: Lower
790-231 Fixed Original Size 1 in Scan XE/DMO-E: 10 (A3SEF), DMO-W: 10
(A3SEF), XC: 89 (8.5x11LEF)
1~255 1: Not defined, 10: A3SEF, 11: A4LEF, 12:A4SEF, 13: A5LEF, 14: A5SEF, 15:
A6LEF, 16: A6SEF, 50: C4 Envelope SEF, 51: C5 Envelope SEF, 55: DL Envelope
LEF, 66: B4SEF, 67: B5LEF, 68: B5SEF, 69: B6LEF, 70: B6SEF, 80: 11x17SEF, 87:
PostcardLEF, 88: PostcardSEF, 89: 8.5x11LEF, 90: 8.5x11SEF, 92: 8.5x14SEF, 94:
12x18SEF, 98: 12x19SEF, 101: 16K LEF, 102: 16K SEF, 104: 8K SEF, 105: Post
-
card (3.5x5.5) LEF, 106: Postcard (3.5x5.5) SEF, 107: Postcard (4x6) LEF, 108:
Postcard (4x6) SEF, 109: Postcard (5x7) LEF, 110: Postcard (5x7) SEF, 111:
5.5x8.5LEF, 112: 5.5x8.5SEF, 113: Postcard (6x9) LEF, 114: Postcard (6x9) SEF,
115: 8x10LEF, 116: 8x10SEF, 118: 8.5x13SEF, 119: 7.25x10.5LEF, 120:
7.25x10.5SEF, 123: Youkei 0 LEF, 124: Choukei 3 SEF, 126: Choukei 4 SEF, 132:
11x15SEF, 135: Photo L LEF, 136: Photo L SEF, 137: Commercial 10 LEF, 139:
215x315mm (8.46x12.4) SEF, 141: SRA3 SEF, 142: Special A3SEF, 143: Special
A4LEF, 144: Special A4SEF, 145: A4 Cover SEF, 146: A4 Cover LEF, 147:
13x19SEF, 148: 13x18SEF, 149: 12.6x19.2SEF, 150: Letter Cover (9x11) SEF, 151:
Letter Cover (9x11) LEF, 152: Monarch Envelope LEF, 154: Prepaid Postcard LEF,
155: Prepaid Postcard SEF, 156: 16K LEF (GCO), 157: 16K SEF (GCO), 159: 8K
SEF (GCO)
790-232 Fixed Original Size 2 in Scan XE/DMO-E: 12 (A4SEF), DMO-W: 12
(A4SEF), XC: 90 (8.5x11SEF)
1~255 Same as above
790-233 Fixed Original Size 3 in Scan XE/DMO-E: 11 (A4LEF), DMO-W: 11
(A4LEF), XC: 118 (8.5x13SEF)
1~255 Same as above
790-234 Fixed Original Size 4 in Scan XE/DMO-E: 14 (A5SEF), DMO-W: 14
(A5SEF), XC: 92 (8.5x14SEF)
1~255 Same as above
Table 9 UI
Chain-
Link Content Default Range Meaning
