Xerox WorkCentre 5225 Service Manual

February, 2008
6-79
WorkCentre 5225, 5230
General Procedures
Launch Version
790-235 Fixed Original Size 5 in Scan XE/DMO-E: 15 (A5LEF), DMO-W: 15
(A5LEF), XC: 132 (11x15SEF)
1~255 Same as above
790-236 Fixed Original Size 6 in Scan XE/DMO-E: 66 (B4SEF), DMO-W: 66
(B4SEF), XC: 80 (11x17SEF)
1~255 Same as above
790-237 Fixed Original Size 7 in Scan XE/DMO-E: 68 (B5SEF), DMO-W: 68
(B5SEF), XC: 112 (5.5x8.5SEF)
1~255 Same as above
790-238 Fixed Original Size 8 in Scan XE/DMO-E: 67 (B5LEF), DMO-W: 67
(B5LEF), XC: 119 (7.25x10.5LEF)
1~255 Same as above
790-239 Fixed Original Size 9 in Scan XE/DMO-E: 70 (B6SEF), DMO-W: 70
(B6SEF), XC: 120 (7.25x10.5SEF)
1~255 Same as above
790-240 Fixed Original Size 10 in Scan XE/DMO-E: 80 (11x17SEF), DMO-W:
80 (11x17SEF), XC: 115 (8x10LEF)
1~255 Same as above
790-241 Fixed Original Size 11 in Scan XE/DMO-E: 92 (8.5x14SEF), DMO-W:
92 (8.5x14SEF), XC: 109 (5x7SEF)
1~255 Same as above
790-242 Download Print from Browser 1 0~1 0: Do not use, 1: Use
790-250 Fixed Size 1 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-251 Fixed Size 1 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-252 Fixed Size 2 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-253 Fixed Size 2 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-254 Fixed Size 3 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-255 Fixed Size 3 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-256 Fixed Size 4 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-257 Fixed Size 4 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-258 Fixed Size 5 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-259 Fixed Size 5 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-260 Fixed Size 6 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-261 Fixed Size 6 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-262 Fixed Size 7 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-263 Fixed Size 7 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-264 Fixed Size 8 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-265 Fixed Size 8 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-266 Fixed Size 9 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-267 Fixed Size 9 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-268 Fixed Size 10 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-269 Fixed Size 10 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-270 Fixed Size 11 Fast Scan NULL (0mm) 0~297 15~297mm. * Initial value is '0'.
790-271 Fixed Size 11 Slow Scan NULL (0mm) 0~432 15~432mm. * Initial value is '0'.
790-272 Top Direction Define in Scan 1 0~1 0: Head to Top, 1: Head to Left
Table 9 UI
Chain-
Link Content Default Range Meaning
