February, 2008
6-83
WorkCentre 5225, 5230
General Procedures
Launch Version
790-421 Copy Custom Func No 1: Customized L1 0~2 0: No customization, 1: Customized L1, 2: Customized L2
790-422 Copy Custom Func L1_1 26 (HB)
3 (FCW)
0~255 Refer to the UI Dialogue Specifications for the setting range as the contents of this
column varies according to the launch. 0: Not set, 1: Color mode, 2: Image Quality
Presets, 3: Original Type, 4: Lighten/Darken / Contrast (Color), 5: Lighten/Darken, 6:
Sharpness/Color Saturation (Color) 7: Sharpness/Color Saturation (BW), 8: Auto
Exposure, 9: Color Balance, 10: Color Shift, 21: 2 Sided, 22: Bound Originals, 23: 2
Sided Book Copy, 24: Original Size, 25: Border Erase, 26: Margin Shift, 27: Image
Rotation, 28: Mirror Image/Negative Image, 29: Original Orientation, 30: Mixed Size
Originals, 41: Copy Output, 42: Booklet Creation, 43: Covers, 44: Transparency
Separators, 45: Multiple-Up, 46: Poster, 47: Repeat Image, 48: Chapter Division/
Inserter/Tab Sheet, 49: Annotation, 50: Set Numbering, 51: Output Side, 52: Fold
-
ing, 61: Build Job, 62: Image Overlay, 63: Delete Outside/Delete Inside, 64: Double
Copy, 65: Tabbed sheet copy, 66: Gloss, 67: Sample copy, 68: High volume copy,
69: HWM, 70: Auto Background Suppression / Contrast, 71: Density/Sharpness/
Brightness, 72: ID card copy, 101: 2 Sided (1->2 Sided (H to H)), 102: 2 Sided (2->2
Sided (H to H)), 103: Mixed Size Originals (Direct selection of parameter), 104: Mar
-
gin Shift (Center), 105: Copy Output (Collate), 106: Copy Output (Staple (One Sta-
ple, Top Left), 107: Copy Output (Staple (Two Staples, Left), 108: Multiple-Up (2Up
(Right->Left)), 109: Multiple-Up (2Up (Right->Left/Top->Bottom)), 110: Output
(Reverse), 111: Folding (Z-fold), 112: Sample Set, 113: Large Volume Document,
114: Double Copy (Direct selection of parameter), 115: Slight Reduction, 116: Auto
Exposure (Direct selection of parameter), 117: Original Orientation (Head to Left)
(Direct selection of parameter), 118: Folding (Direct selection of parameter), 119:
Build Job (Direct selection of parameter), 120: Image Overlay (Direct selection of
parameter), 121: Sort (punch [left dual]), 122: Upper-left single staple / left dual sta
-
ple, 123: Left dual staple / left dual punch, 124: 2 sheets --> 1 sheet / 4 sheets ---> 1
sheet
(See UI Dialogue specification for target range because descriptions in this column
include information not relevant to all products and products at different stage after
launch.)
790-423 Copy Custom Func L1_2 25 (HB-UI), 41 (FCW-UI) 0~255 Same as above
790-424 Copy Custom Func L1_3 5 (HB-UI), 45 (FCW-UI) 0~255 Same as above
790-425 Copy Custom Func L2_1 26 (HB-UI B/W, FCW-UI),
1 (HB-UI Color)
0~255 Same as above
790-426 Copy Custom Func L2_2 3 (HB-UI), 25 (FCW-UI) 0~255 Same as above
790-427 Copy Custom Func L2_3 5 (HB-UI), 30 (FCW-UI) 0~255 Same as above
790-428 Copy Custom Func L2_4 0 (HB-UI), 3 (FCW-UI) 0~255 Same as above
790-429 Copy Custom Func L2_5 0 (HB-UI), 21 (FCW-UI) 0~255 Same as above
790-430 Copy Custom Func L2_6 0 (HB-UI), 41 (FCW-UI) 0~255 Same as above
790-431 Copy Custom Func L2_7 0 (HB-UI), 45 (FCW-UI) 0~255 Same as above
790-432 Scan Custom Func No 0: No customization 0~1 0: No customization, 1: Customized L1
790-433 Scan Custom Func 1 0: Not set 0~255 0: Not set, 1: 2 Sided, 2: Scan Resolution, 3: Lighten/Darken, 4: Reduce/Enlarge
790-434 Scan Custom Func 2 0: Not set 0~255 0: Not set, 1: 2 Sided, 2: Scan Resolution, 3: Lighten/Darken, 4: Reduce/Enlarge
Table 9 UI
Chain-
Link Content Default Range Meaning
To Next Page
