Xerox WorkCentre 5225 Service Manual

February, 2008
6-82
WorkCentre 5225, 5230
Launch Version
General Procedures
790-401 1-Menu Display Customize Service Set XE/DMO-E: 1 (Copy), DMO-W: 1
(Copy), XC: 1 (Copy)
0~255 0: No features, 1: Copy, 2: FAX/iFAX, 3: Scan to E-mail, 4: Scan to Mailbox, 5: Scan
to Server, 6: Scan to PC, 7: BOX, 8: Print, 9: Job Flow Service, 10: Job Memory, 11:
Multi Service, 12: Gemini, 13: DocuShare, 14: Media Print, 101: Auto Gradation
Adjustment, 102: FAX Receive mode, 103: Activity Report, 104: Language, 105:
Create, 106: Printer mode, 107: Help
790-402 2-Menu Display Customize Service Set XE/DMO-E: 3 (Scan to E-mail), DMO-
W: 3 (Scan to E-mail), XC: 3 (Scan to
E-mail)
0~255 Same as above
790-403 3-Menu Display Customize Service Set XE/DMO-E: 2 (FAX/iFAX), DMO-W: 2
(FAX/iFAX), XC: 2 (FAX/iFAX)
0~255 Same as above
790-404 4-Menu Display Customize Service Set XE/DMO-E: 5 (Scan to Server), DMO-
W: 5 (Scan to Server), XC: 5 (Scan to
Server)
0~255 Same as above
790-405 5-Menu Display Customize Service Set XE/DMO-E: 4 (Scan to MailBox),
DMO-W: 4 (Scan to MailBox), XC: 4
(Scan to MailBox)
0~255 Same as above
790-406 6-Menu Display Customize Service Set XE/DMO-E: 0 (No feature), DMO-W: 0
(No feature), XC: 0 (No feature)
0~255 Same as above
790-407 7-Menu Display Customize Service Set XE/DMO-E: 0 (No feature), DMO-W: 0
(No feature), XC: 0 (No feature)
0~255 Same as above
790-408 8-Menu Display Customize Service Set XE/DMO-E: 0 (No feature), DMO-W: 0
(No feature), XC: 0 (No feature)
0~255 Same as above
790-409 9-Menu Display Customize Service Set XE/DMO-E: 0 (No feature), DMO-W: 0
(No feature), XC: 0 (No feature)
0~255 Same as above
790-410 10-Menu Display Customize Service Set XE/DMO-E: 6 (Scan to PC), DMO-W:
6 (Scan to PC), XC: 6 (Scan to PC)
0~255 Same as above
790-411 11-Menu Display Customize Service Set XE/DMO-E: 7 (Box), DMO-W: 7 (Box),
XC: 7 (Box)
0~255 Same as above
790-412 12-Menu Display Customize Service Set XE/DMO-E: 105 (Create), DMO-W:
105 (Create), XC: 105 (Create)
0~255 Same as above
790-413 13-Menu Display Customize Service Set XE/DMO-E: 10 (Job Memory), DMO-
W: 10 (Job Memory), XC: 10 (Job
Memory)
0~255 Same as above
790-414 14-Menu Display Customize Service Set XE/DMO-E: 0 (No feature), DMO-W: 0
(No feature), XC: 0 (No feature)
0~255 Same as above
790-415 15-Menu Display Customize Service Set XE/DMO-E: 0 (No feature), DMO-W: 0
(No feature), XC: 0 (No feature)
0~255 Same as above
790-416 16-Menu Display Customize Service Set XE/DMO-E: 0 (No feature), DMO-W: 0
(No feature), XC: 0 (No feature)
0~255 Same as above
790-417 1-Menu Display Utility Service Set 0: Not set 0~255 0: Not set, 101: Auto Gradation Adjustment, 102: FAX Receive mode, 103: Activity
Report, 104: Language, 105: Create, 160: Printer mode, 107: Help
790-418 2-Menu Display Utility Service Set 0: Not set 0~255 Same as above
790-419 3-Menu Display Utility Service Set 0: Not set 0~255 Same as above
790-420 4-Menu Display Utility Service Set 0: Not set 0~255 Same as above
Table 9 UI
Chain-
Link Content Default Range Meaning
