Xerox WorkCentre 5225 Service Manual

February, 2008
6-86
WorkCentre 5225, 5230
Launch Version
General Procedures
Chain 790-xxx Copy Service
790-630 Virtual Address Book 0 0~6 0: Address Book 3: 3-digit Virtual Address Book 4: 4-digit Virtual Address Book 5: 5-
digit Virtual Address Book 6: 6-digit Virtual Address Book (* Settings 1 and 2 are not
allowed)
790-631 Address Book NVM Data Transfer To New
HDD
0 0~1 0: Do not transfer 1: Transfer
Table 9 UI
Chain-
Link Content Default Range Meaning
Table 10 Copy Service
Chain-
Link
Content Default Range Meaning
790-600 Poster Overlap Width 10mm 1~25 10mm~25mm
790-605 Sample Copy Enable 0: Disable 0~1 0: Disable, 1: Enable
790-606 Annotation Page No-Pattern 1 1~6 1: N, 2: -N-, 3: Page N, 4: N/M, 5: -N/M-, 6: Page N/M
790-607 Annotation Page No-Position 6 1~6 1: Top Left, 2: Top Right, 3: Top Center, 4: Bottom Left, 5: Bottom Right, 6: Bottom Center
790-609 Annotation Page No-Position_Side2 0 0~1 0: Opposite to Side 1, 1: Same as Side 1
790-611 Annotation Date-Position 5 1~6 1: Top Left, 2: Top Right, 3: Top Center, 4: Bottom Left, 5: Bottom Right, 6: Bottom Center
790-613 Annotation Date-Position_Side2 0 0~1 0: Opposite to Side 1, 1: Same as Side 1
790-614 Annotation Stamp-Position 2 1~9 1: Top Left, 2: Top Right, 3: Top Center, 4: Bottom Left, 5: Bottom Right, 6: Bottom Center, 7:
Left Center, 8: Right Center 9: Center
790-617 Annotation Stamp-Density 0 0~2 0: 0% (solid), 1: [25%], 2: [50%]
790-618 Annotation Stamp-Position_side2 1 0~1 0: Opposite to Side 1, 1: Same as Side 1
790-619 Annotation Stamp-dirCheck 1 0~1 0: Set for first sheet, 1: Set for each sheet
790-620 Allover Copy Enable 1 1~2 1: Do not copy whole image (copy all with reduction), 2: Copy whole image
790-632 Added Thumbnail Default Net 1 0~1 0: Do not add, 1: Add
790-633 Added Thumbnail Default Mail 0 0~1 0: Do not add, 1: Add
790-639 Default Copy - Staple Position Information Automatically set at the
time of initiation
0~255 Logical OR of the following:
0x01: Single at left trail edge
0x02: Single at right trail edge
0x04: Single at center trail edge
0x08: Dual at center trail edge
0x10: Quad at center trail edge
790-640 Paper Change Display 0 0~255 0: Do not display, 1: Display
790-641 Paper Color Display 1 1~1 1: Display
790-642 Paper Information Display 1 0~255 0: Do not display, 1: Display applied size, 2: Display hole-punch attribute
790-661 Report Store Box ID 1 1~500 Box Number
790-662 Consumable Auto Display Timing 0 0~2 0: Do not display, 1: Display only when system becomes ready after power is turned on and
initialization sequence completes, 2: Display each time auto clear occurs
790-664 Address Book Import Mode 0 0~1 0: Addition mode, 1: Replacement mode
790-665 Default Display Tray Setting 1 0~1 0: Disable, 1: Enable
790-666 Display DADF FAX Read Mode 1 0~1 0: Do not display, 1: Display

Xerox WorkCentre 5225 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Internal memory	No MB
Type	Digital copier
