Xerox WorkCentre 5225 Service Manual

February, 2008
6-94
WorkCentre 5225, 5230
Launch Version
General Procedures
800-020 Error Diffusion Initial [K-Light] 1 0~64 0 to 64
800-023 Error Diffusion Initial [K-Normal] 1 0~64 0 to 64
800-026 Error Diffusion Initial [K-Dark] 3 0~64 0 to 64
800-029 Error Diffusion Step [K-Light] 3 1~20 1 to 20
800-032 Error Diffusion Step [K-Normal] 4 1~20 1 to 20
800-035 Error Diffusion Step [K-Dark] 4 1~20 1 to 20
800-039 Signature Legacy Mode 0 0~1 0: With margin (Process in the ordinary way).
1: Without margin (Emulate conventional machine type failure [AR86313]).
800-040 Dither Value of Sublimit [K-Light] 12 0~128 0 to 128
800-043 Dither Value of Sublimit [K-Normal] 16 0~128 0 to 128
800-046 Dither Value of Sublimit [K-Dark] 24 0~128 0 to 128
803-505 HPGL Job Mem Current 0 0~1 0: HP750c, 1: FX4036
803-506 HPGL Job Mem 1 0 0~1 0: HP750c, 1: FX4036
803-507 HPGL Job Mem 2 0 0~1 0: HP750c, 1: FX4036
803-508 HPGL Job Mem 3 0 0~1 0: HP750c, 1: FX4036
803-509 HPGL Job Mem 4 0 0~1 0: HP750c, 1: FX4036
803-510 HPGL Job Mem 5 0 0~1 0: HP750c, 1: FX4036
803-511 HPGL Job Mem 6 0 0~1 0: HP750c, 1: FX4036
803-512 HPGL Job Mem 7 0 0~1 0: HP750c, 1: FX4036
803-513 HPGL Job Mem 8 0 0~1 0: HP750c, 1: FX4036
803-514 HPGL Job Mem 9 0 0~1 0: HP750c, 1: FX4036
803-515 HPGL Job Mem 10 0 0~1 0: HP750c, 1: FX4036
803-516 HPGL Job Mem 11 0 0~1 0: HP750c, 1: FX4036
803-517 HPGL Job Mem 12 0 0~1 0: HP750c, 1: FX4036
803-518 HPGL Job Mem 13 0 0~1 0: HP750c, 1: FX4036
803-519 HPGL Job Mem 14 0 0~1 0: HP750c, 1: FX4036
803-520 HPGL Job Mem 15 0 0~1 0: HP750c, 1: FX4036
803-521 HPGL Job Mem 16 0 0~1 0: HP750c, 1: FX4036
803-522 HPGL Job Mem 17 0 0~1 0: HP750c, 1: FX4036
803-523 HPGL Job Mem 18 0 0~1 0: HP750c, 1: FX4036
803-524 HPGL Job Mem 19 0 0~1 0: HP750c, 1: FX4036
803-525 HPGL Job Mem 20 0 0~1 0: HP750c, 1: FX4036
805-781 TIFF Logical Printer 1 Bypass Tray Feed
Direction
0 0~1 0: Higher priority on SEF
1: Higher priority on LEF
805-782 TIFF Logical Printer 2 Bypass Tray Feed
Direction
0 0~1 0: Higher priority on SEF
1: Higher priority on LEF
805-783 TIFF Logical Printer 3 Bypass Tray Feed
Direction
0 0~1 0: Higher priority on SEF
1: Higher priority on LEF
805-784 TIFF Logical Printer 4 Bypass Tray Feed
Direction
0 0~1 0: Higher priority on SEF
1: Higher priority on LEF
Table 11 Print Service
Chain-
Link Content Default Range Meaning
