Xerox WorkCentre 5225 Service Manual

February, 2008
6-93
WorkCentre 5225, 5230
General Procedures
Launch Version
Chain 800-xxx Print Service
810-270 Annotation Horizontal Bates Numbering
Adjust Top Right
12 0~200 0 to 200: Setting value x 0.5 (mm)
810-271 Annotation Vertical Bates Numbering
Adjust Top Right
12 0~200 0 to 200: Setting value x 0.5 (mm)
810-272 Annotation Horizontal Bates Numbering
Adjust Top Center
200 0~400 0 to 400: Setting value x 0.5 (mm)
810-273 Annotation Vertical Bates Numbering
Adjust Top Center
12 0~200 0 to 200: Setting value x 0.5 (mm)
810-274 Annotation Horizontal Bates Numbering
Adjust Bottom Left
12 0~200 0 to 200: Setting value x 0.5 (mm)
810-275 Annotation Vertical Bates Numbering
Adjust Bottom Left
12 0~200 0 to 200: Setting value x 0.5 (mm)
810-276 Annotation Horizontal Bates Numbering
Adjust Bottom Right
12 0~200 0 to 200: Setting value x 0.5 (mm)
810-277 Annotation Vertical Bates Numbering
Adjust Bottom Right
12 0~200 0 to 200: Setting value x 0.5 (mm)
810-278 Annotation Horizontal Bates Numbering
Adjust Bottom Center
200 0~400 0 to 400: Setting value x 0.5 (mm)
810-279 Annotation Vertical Bates Numbering
Adjust Bottom Center
12 0~200 0 to 200: Setting value x 0.5 (mm)
Table 10 Copy Service
Chain-
Link Content Default Range Meaning
Table 11 Print Service
Chain-
Link
Content Default Range Meaning
800-001 APS Job Recovery Method 6 6: Displays add paper message (SPS Off), 5: Uses a larger paper size (no adjustment), 2:
Uses nearest paper size (with adjustment), 8: Feed from Bypass tray
800-002 Index Print - Select 0 0~3 0: Not specified, 1: Do not perform Index Print, 2: Print only tab section, 3: Print page and
tab section
800-003 Index Print - Shift 130 0~150 1 to 150 (unit: 0.1mm)
800-004 Default Output Tray for E-Mail Printing No C/D Finisher: 0
C/D Finisher: 4
HCS1: 5
0~127 0: Center Tray, 1: Side Tray, 2: Finisher Tray, 3: Center Tray2, 4: Top Tray, 5: HCS1 Top
Tray, 6: HCS1 Stacker Tray, 33 to 42: Mailbox 1 to 10, 127: AUTO
(Uninstalled options cannot be selected.)
800-005 PJL EOJ Filter for RAW I/F 0 0~1 0: Make @PJL EOJ command valid and terminate job.
1: Ignore @PJL EOJ command and do not terminate job.
800-006 Expand Print Mode 1: Standard 1~2 1: Standard, 2: Expanded
800-016 ID Print Stamp Position or Enable 5: Disable 1~5 1: Top Left, 2: Top Right, 3: Bottom Left, 4: Bottom Right, 5: Disable
800-017 Device Print Permission 1 0~1 1: Allow device print 0: Prohibit device print
800-018 Force Extend Print 1 1~2 1: Do not force copying of whole images, 2: Force copying of whole images (For Katakana,
installed from P/L)
800-019 XPS Print Ticket Mode 2 1~3 1: Do not process, 2: Standard, 3: Compatible with Microsoft specification
