Xerox WorkCentre 5225 Service Manual

February, 2008
6-92
WorkCentre 5225, 5230
Launch Version
General Procedures
810-205 Annotation Vertical Stamp Adjust Bottom
Center
28 0~200 0 to 200: Set value x 0.5mm
810-206 Annotation Horizontal Stamp Adjust Left
Center
28 0~200 0 to 200: Set value x 0.5mm
810-207 Annotation Vertical Stamp Adjust Left Cen-
ter
200 0~400 0 to 400: Set value x 0.5mm
810-208 Annotation Horizontal Stamp Adjust Right
Center
28 0~200 0 to 200: Set value x 0.5mm
810-209 Annotation Vertical Stamp Adjust Right
Center
200 0~400 0 to 400: Set value x 0.5mm
810-210 Annotation Horizontal Stamp Adjust Center 200 0~400 0 to 400: Set value x 0.5mm
810-211 Annotation Vertical Stamp Adjust Center 200 0~400 0 to 400: Set value x 0.5mm
810-212 Annotation Horizontal Back Side Page 200 0~400 0 to 400: Set value x 0.5mm
810-213 Annotation Vertical Back Side Page 200 0~400 0 to 400: Set value x 0.5mm
810-214 Annotation Stamp String 1 Null 64 + 1 bytes (32 two-byte characters, 64 one-byte characters)
810-215 Annotation Stamp String 2 Null 64 + 1 bytes (32 two-byte characters, 64 one-byte characters)
810-216 Annotation Stamp String 3 Null 64 + 1 bytes (32 two-byte characters, 64 one-byte characters)
810-217 Annotation Stamp String 4 Null 64 + 1 bytes (32 two-byte characters, 64 one-byte characters)
810-218 Annotation Stamp String 5 Null 64 + 1 bytes (32 two-byte characters, 64 one-byte characters)
810-219 Annotation Stamp String 6 Null 64 + 1 bytes (32 two-byte characters, 64 one-byte characters)
810-220 Annotation Stamp String 7 Null 64 + 1 bytes (32 two-byte characters, 64 one-byte characters)
810-221 Annotation Stamp String 8 Null 64 + 1 bytes (32 two-byte characters, 64 one-byte characters)
810-222 Analog Watermark String 1 Null 32 + 1 bytes (16 two-byte characters, 32 one-byte characters)
810-223 Analog Watermark String 2 Null 32 + 1 bytes (16 two-byte characters, 32 one-byte characters)
810-224 Analog Watermark String 3 Null 32 + 1 bytes (16 two-byte characters, 32 one-byte characters)
810-225 Annotation Stamp - Font Size 48 1~255 6 to 64 (points)
810-226 Annotation Date - Font Size 10 1~255 6 to 64 (points)
810-227 Annotation Page No. - Font Size 10 1~255 6 to 64 (points)
810-228 Annotation Stamp String 1 1~71 1: CONFIDENTIAL, 2: VOID, 4: Copy Prohibited, 6: IMPORTANT, 7: Circulate, 8: URGENT,
9: Ignore Side 2, 10: DRAFT
810-229 AWM String 4 1~34 3: Duplicate, 4: Copy prohibited, 5: Copy
810-264 Annotation Bates Numbering Digits 0 0~9 0: Not specified, 1 to 9: 1 to 9 digits
810-265 Annotation Bates Numbering Position 6 1~6 1: Upper left, 2: Upper right, 3: Upper center, 4: Lower left, 5: Lower right, 6: Lower center
810-266 Annotation Bates Numbering Size 10 6~24 6 to 24 (points)
810-267 Annotation Bates Numbering Position Side
2
1 0~1 0: Symmetrical position, 1: Same position
810-268 Annotation Horizontal Bates Numbering
Adjust Top Left
12 0~200 0 to 200: Setting value x 0.5 (mm)
810-269 Annotation Vertical Bates Numbering
Adjust Top Left
12 0~200 0 to 200: Setting value x 0.5 (mm)
Table 10 Copy Service
Chain-
Link Content Default Range Meaning
