Xerox WorkCentre 5225 Service Manual

February, 2008
6-101
WorkCentre 5225, 5230
General Procedures
Launch Version
825-064 Dial Tone Detection before Dial for Ch0 1 0~1 0: Do not detect, 1: Detect
825-065 Dial Tone Detection before Dial for Ch1 1 0~1 0: Do not detect, 1: Detect
825-066 Dial Tone Detection before Dial for Ch2 1 0~1 0: Do not detect, 1: Detect
825-067 Dial Tone Detection before Dial for Ch3 1 0~1 0: Do not detect, 1: Detect
825-068 Dial Tone Detection before Dial for Ch4 1 0~1 0: Do not detect, 1: Detect
825-069 Dial Tone Detection before Dial for Ch5 1 0~1 0: Do not detect, 1: Detect
825-070 Dial Tone Detection before Dial for PBX 0 0~1 0: Do not detect, 1: Detect
825-071 Time of Tone Detection before Dial for Ch0 4 0~255 0~255 (sec.)
825-072 Time of Tone Detection before Dial for Ch1 10 0~255 0~255 (sec.)
825-073 Time of Tone Detection before Dial for Ch2 10 0~255 0~255 (sec.)
825-074 Time of Tone Detection before Dial for Ch3 10 0~255 0~255 (sec.)
825-075 Time of Tone Detection before Dial for Ch4 10 0~255 0~255 (sec.)
825-076 Time of Tone Detection before Dial for Ch5 10 0~255 0~255 (sec.)
825-077 Dialing Restriction for Ch0 0 0: Allow 1: Restrict
825-078 Dialing Restriction for Ch1 0 0: Allow 1: Restrict
825-079 Dialing Restriction for Ch2 0 0: Allow 1: Restrict
825-080 Dialing Restriction for Ch3 0 0: Allow 1: Restrict
825-081 Dialing Restriction for Ch4 0 0: Allow 1: Restrict
825-082 Dialing Restriction for Ch5 0 0: Allow 1: Restrict
825-103 RX Gain in G3 Transmission Mode 6 (-6dB) 0~15 0~15 (0~-15dB)
825-104 TX Gain in ISDN G3 Transmission Mode 0 0~15 0~15 (0~-15dB)
825-110 TEI (TEI acquisition method = valid when
assigned manually)
0 0~63 0 to 63
825-111 TEI Acquisition Method 0 0~1 0: Assign manually, 1: Assign automatically
825-115 PB Pause Time. Inter-digit Pause Time in
PB (DTMF) Dial
102 0~255 0 to 255 (ms)
825-127 Analogue Sending Dropoff by Modem for
Ch0
8 8~15 8dBm (8) ~ 15 (15) dBm -1dBm increments
825-128 Analogue Sending Dropoff by Modem for
Ch1
8 8~15 8dBm (8) ~ 15 (15) dBm -1dBm increments
825-129 Analogue Sending Dropoff by Modem for
Ch2
8 8~15 8dBm (8) ~ 15 (15) dBm -1dBm increments
825-130 Analogue Sending Dropoff by Modem for
Ch3
15 8~15 8dBm (8) ~ 15 (15) dBm -1dBm increments
825-131 Analogue Sending Dropoff by Modem for
Ch4
8 8~15 8dBm (8) ~ 15 (15) dBm -1dBm increments
825-132 Analogue Sending Dropoff by Modem for
Ch5
15 8~15 8dBm (8) ~ 15 (15) dBm -1dBm increments
825-133 Busy Tone Detection Enable 1: Detect 0~1 0: Do not detect, 1: Detect
825-134 Dial Tone Detection Enable 0: Do not detect 0~1 0: Do not detect, 1: Detect
Table 12 FAX Service
Chain-
Link Content Default Range Meaning
