Xerox WorkCentre 5225 Service Manual

February, 2008
6-102
WorkCentre 5225, 5230
Launch Version
General Procedures
825-158 Transmission Completion Number on
Transmission Log
0 0~1 0: Total Number of sheets transmitted not including those resent 1: Total Number of sheets
transmitted for each line connection
825-159 ECM Ability 1: Enable 0~1 0: Disable, 1: Enable
825-160 CNG Sending Time 60 (3000ms) 20~140 1sec (20) ~ 7sec (140) (1 unit = 50msec)
825-161 CED Hz 1 0~1 0: 1080Hz 1: 2100Hz
825-162 T1 Timer Value on FAX Receiving 39sec 1~90 1~90 (sec.)
825-163 Silent Time 0 0~1 0: 75msec, 1: 1sec
825-164 Enable FSK Detection before Receiving
Image (Non-ECM)
1: Detect 0~1 0: Do not detect, 1: Detect
825-165 Enable FSK Detection before Receiving
0: Do not detect 0~1 0: Do not detect, 1: Detect
825-166 G3M CSI Send 0: Transmit 0~1 0: Transmit, 1: Off
825-168 Local Name Send 1: On 0~1 0: Off, 1: On
825-169 Local Name Resend 0: Do not resend 0~1 0: Do not resend, 1: Resend
825-170 ECM Frame Size 0 0: 256 bytes, 1: 64 bytes
825-171 G3M ECM T5 Time 0: 1(min) 0: 1 (min.) 1: 3 (min.) 2: No limit
825-173 RTN Command Sending Threshold (Ratio) 0: 5% 0: 5% 1: 10% 2: 15% 3: 20%
825-174 RTN Command Sending Threshold (Line) 2 0: No limit 1: 3 lines 2: 6 lines 3: 12 lines
825-175 DIS/DTC FIF Sending Byte Number 0 0: No limit 1: 4-byte system
825-176 EMC Ability 1: Enable 0~1 0: Disable, 1: Enable
825-177 CCITT Trellis Ability 2 0: V.27ter and below 1: V.29 and below 2: V.17 and below
825-178 CCITT Trellis Ability (International Commu-
nications)
2 0: V.27ter and below 1: V.29 and below 2: V.17 and below
825-179 ECM Block Synchronize for Ch0 0 0: 200ms, 1: 500ms, 2: 1sec
825-180 ECM Block Synchronize for Ch1 0 0: 200ms, 1: 500ms, 2: 1sec
825-181 ECM Block Synchronize for Ch2 0 0: 200ms, 1: 500ms, 2: 1sec
825-182 ECM Block Synchronize for Ch3 0 0: 200ms, 1: 500ms, 2: 1sec
825-183 ECM Block Synchronize for Ch4 0 0: 200ms, 1: 500ms, 2: 1sec
825-184 ECM Block Synchronize for Ch5 0 0: 200ms, 1: 500ms, 2: 1sec
825-185 ECM CTC Number for Ch0 5 0~7 0=000 ~ 7=111
825-186 ECM CTC Number for Ch1 5 0~7 0=000 ~ 7=111
825-187 ECM CTC Number for Ch2 5 0~7 0=000 ~ 7=111
825-188 ECM CTC Number for Ch3 5 0~7 0=000 ~ 7=111
825-189 ECM CTC Number for Ch4 5 0~7 0=000 ~ 7=111
825-190 ECM CTC Number for Ch5 5 0~7 0=000 ~ 7=111
825-191 ECM CTC Speed Shift Down for Ch0 1 0: DO NOT SHIFT DOWN, 1: SHIFT DOWN
825-192 ECM CTC Speed Shift Down for Ch1 1 0: DO NOT SHIFT DOWN, 1: SHIFT DOWN
825-193 ECM CTC Speed Shift Down for Ch2 1 0: DO NOT SHIFT DOWN, 1: SHIFT DOWN
825-194 ECM CTC Speed Shift Down for Ch3 1 0: DO NOT SHIFT DOWN, 1: SHIFT DOWN
825-195 ECM CTC Speed Shift Down for Ch4 1 0: DO NOT SHIFT DOWN, 1: SHIFT DOWN
Table 12 FAX Service
Chain-
Link Content Default Range Meaning
