Xerox WorkCentre 5225 Service Manual

February, 2008
6-105
WorkCentre 5225, 5230
General Procedures
Launch Version
825-244 G3 TX Modem MAX Speed for Ch5 on V.34 14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-245 G3 TX Modem MAX Speed for Ch0 on V.34
Overseas
14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-246 G3 TX Modem MAX Speed for Ch1 on V.34
Overseas
14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-247 G3 TX Modem MAX Speed for Ch2 on V.34
Overseas
14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-248 G3 TX Modem MAX Speed for Ch3 on V.34
Overseas
14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-249 G3 TX Modem MAX Speed for Ch4 on V.34
Overseas
14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-250 G3 TX Modem MAX Speed for Ch5 on V.34
Overseas
14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-251 G3 RX Cable Equalizer for Ch0 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-252 G3 RX Cable Equalizer for Ch1 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-253 G3 RX Cable Equalizer for Ch2 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-254 G3 RX Cable Equalizer for Ch3 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-255 G3 RX Cable Equalizer for Ch4 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-256 G3 RX Cable Equalizer for Ch5 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-257 G3 TSI / CIG Send TSI for Ch0 0 0 to 255. 0: AUTO, 1: Forced transmission, 2: Do not transmit
825-263 G3 TX Cable Equalizer for Ch0 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-264 G3 TX Cable Equalizer for Ch1 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-265 G3 TX Cable Equalizer for Ch2 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-266 G3 TX Cable Equalizer for Ch3 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-267 G3 TX Cable Equalizer for Ch4 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-268 G3 TX Cable Equalizer for Ch5 1 0: 0dB 1: 4dB 2: 8dB 3: 12dB
825-274 Error Line Control 0: No limit 0: No limit 1: 128 lines 2: 256 lines 3: 512 lines 4: 1024 lines 5: 2048 lines
825-275 Error Judge Selection on RTN Sending 0: Proportion 0: Proportion 1: Number of lines
825-276 Tone Receiving Detect Level for Ch0 1: -43dBm 0: -48dBm 1: -43dBm 2: -38dBm 3: -33dBm
825-277 Tone Receiving Detect Level for Ch1 1: -43dBm 0: -48dBm 1: -43dBm 2: -38dBm 3: -33dBm
825-278 Tone Receiving Detect Level for Ch2 1: -43dBm 0: -48dBm 1: -43dBm 2: -38dBm 3: -33dBm
825-279 Tone Receiving Detect Level for Ch3 1: -43dBm 0: -48dBm 1: -43dBm 2: -38dBm 3: -33dBm
825-280 Tone Receiving Detect Level for Ch4 1: -43dBm 0: -48dBm 1: -43dBm 2: -38dBm 3: -33dBm
825-281 Tone Receiving Detect Level for Ch5 1: -43dBm 0: -48dBm 1: -43dBm 2: -38dBm 3: -33dBm
Table 12 FAX Service
Chain-
Link Content Default Range Meaning
