Xerox WorkCentre 5225 Service Manual

February, 2008
6-106
WorkCentre 5225, 5230
Launch Version
General Procedures
825-285 Transmission Declaration Paper Size 0x014c 0726: A3, A4, B4,
A4LEF, A5LEF, B5LEF,
Letter, Legal, Ledger, Let
-
ter LEF
0x0000 0002: A3 0x0000 0004: A4 0x0000 0020: B4 0x0000 0100: Letter 0x0000 0200:
Legal 0x0000 0400: Ledger 0x0000 0800: 8.5x13” 0x0004 0000: A4LEF 0x0008 0000:
A5LEF 0x0040 0000: B5LEF 0x0100 0000: Letter LEF 0x0200 0000: Letter Half LEF
825-322 V34 Modulate Ability Enable 1=On 0~1 0=Off, 1=On
825-417 For TEI (TEI acquisition method = valid
when assigned manually) Option Board 2
1 0~63 0 to 63
825-421 CED Start Time 2=1.0sec 0~3 0=2.0sec 1=0.2sec 2=1.0sec 3=2.3sec
825-422 Outside Line Number Detect TX Mode Ch0 0: Do not set (Follow
machine settings)
0~2 0: Do not set (Follow machine settings), 1: If the 1st digit of the dial data (calling) is detected
as the outside line recognition number, transmission will be in V.34. If it is different from the
outside line recognition number, transmission will be in other than V.34, 2: If the 1st digit of
the dial data (calling) is detected as the outside line recognition number, transmission will be
in other than V.34. If it is different from the outside line recognition number, transmission will
be in V.34
825-423 Outside Line Number Detect TX Mode Ch1 0: Do not set (Follow
machine settings)
0~2 0: Do not set (Follow machine settings), 1: If the 1st digit of the dial data (calling) is detected
as the outside line recognition number, transmission will be in V.34. If it is different from the
outside line recognition number, transmission will be in other than V.34, 2: If the 1st digit of
the dial data (calling) is detected as the outside line recognition number, transmission will be
in other than V.34. If it is different from the outside line recognition number, transmission will
be in V.34
825-424 Outside Line Number Detect TX Mode Ch2 0: Do not set (Follow
machine settings)
0~2 0: Do not set (Follow machine settings), 1: If the 1st digit of the dial data (calling) is detected
as the outside line recognition number, transmission will be in V.34. If it is different from the
outside line recognition number, transmission will be in other than V.34, 2: If the 1st digit of
the dial data (calling) is detected as the outside line recognition number, transmission will be
in other than V.34. If it is different from the outside line recognition number, transmission will
be in V.34
825-425 Outside Line Number Detect TX Mode Ch3 0: Do not set (Follow
machine settings)
0~2 0: Do not set (Follow machine settings), 1: If the 1st digit of the dial data (calling) is detected
as the outside line recognition number, transmission will be in V.34. If it is different from the
outside line recognition number, transmission will be in other than V.34, 2: If the 1st digit of
the dial data (calling) is detected as the outside line recognition number, transmission will be
in other than V.34. If it is different from the outside line recognition number, transmission will
be in V.34
825-426 Outside Line Number Detect TX Mode Ch4 0: Do not set (Follow
machine settings)
0~2 0: Do not set (Follow machine settings), 1: If the 1st digit of the dial data (calling) is detected
as the outside line recognition number, transmission will be in V.34. If it is different from the
outside line recognition number, transmission will be in other than V.34, 2: If the 1st digit of
the dial data (calling) is detected as the outside line recognition number, transmission will be
in other than V.34. If it is different from the outside line recognition number, transmission will
be in V.34
825-427 Outside Line Number Detect TX Mode Ch5 0: Do not set (Follow
machine settings)
0~2 0: Do not set (Follow machine settings), 1: If the 1st digit of the dial data (calling) is detected
as the outside line recognition number, transmission will be in V.34. If it is different from the
outside line recognition number, transmission will be in other than V.34, 2: If the 1st digit of
the dial data (calling) is detected as the outside line recognition number, transmission will be
in other than V.34. If it is different from the outside line recognition number, transmission will
be in V.34
825-428 Outside Line Detect Number Ch0 0 0~11 0: 0 ~ 9: 9, 10: #, 11: *
Table 12 FAX Service
Chain-
Link Content Default Range Meaning
