YASKAWA CIMR-G5A Series User Manual

Setting User Constants
4.2.5 Initialize Mode
4-18
A
EXAMPLE
"
Changing Monitor Display to Output Current at Startup in Basic Access Level
Use the following procedure to change user constant o1-02 so that the output current is displayed at startup.
(The procedure continues from the end of the previous example.)
Step Key Sequence Digital Operator Display Remarks
1

User Monitor Sel
Output kWatts
Check the display.
2
Power-On Monitor
Frequency Ref
3
DATA
ENTER
o1−02 = 1:::
Frequency Ref
4
Press twice.
o1−02 = 3
Output Current
5
DATA
ENTER
Entry Accepted
Writes-in the new setting.
Power-On Monitor
Output Current
After a few seconds, the Operator dis-
play is as shown on the left.
6
ESC
Function o1
Monitor Select
7
ESC
G5: Main Menu :
Programming
Output current has been set in monitor selection after power ON.
4.2.5 Initialize Mode
The initialize mode is used to select the language displayed by the Unit, the access level, and the control
method; it is also used to initialize the Unit’s user constants. The structure of the initialize mode is shown
in Figure 4.7.
Operation mode
Initialize mode
Programming mode
Language
Password
Function Selection A2
Access level
Control mode
Initialize
A2-02 User Pram 2
A2-32 User Pram 32
A2-01 User Pram 1
Accessible/settable only in Advanced setting level.
MENU
Fig
4.7 Structure of Initialize Mode User Constants
4
