5.2 b: Application
152 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
The parameters necessary that control the PI Sleep/Snooze function are explained below.
■
b5-15: PI Sleep Function Start Level
Sets the level that triggers PI Sleep.
The drive goes into Sleep mode if the PI output or frequency reference is smaller than b5-15 for longer than the time set
in b5-16. It resumes the operation when the PI output or frequency reference is above b5-15 for longer than the time set
in b5-16.
■
b5-16: PI Sleep Delay Time
Sets the delay time to activate or deactivate the PI Sleep function.
No. Name Setting Range Default
b5-15 PI Sleep Function Start Level 0.0 to 200.0 Hz 0.0 Hz
No. Name Setting Range Default
b5-16 PI Sleep Delay Time 0.0 to 25.5 s 0.0 s
PI Setpoint
b5-25 PI Setpoint
Boost Setting
PI Feedback
b5-24
PI Snooze
Deactivation
Level
SFS Output frequency
t<b5-23
b5-22
PI Snooze Level
b5-23
PI Snooze
Delay Time
PI Setpoint+ b5-25
Deceleration
Boost
PI operation
Time
Time
Time
Snooze function activated
b5-27 Snooze
Feedback Level
b5-26 PI Boost
Maximum Time
Snooze mode
PI operation
common_TMonly
