D.2 European Standards
440 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
D.2 European Standards
Figure D.1
Figure D.1 CE Mark
The CE mark indicates compliance with European safety and environmental regulations. It is required for engaging in
business and commerce in Europe.
European standards include the Machinery Directive for machine manufacturers, the Low Voltage Directive for
electronics manufacturers, and the EMC guidelines for controlling noise.
This drive displays the CE mark based on the EMC guidelines and the Low Voltage Directive.
• Low Voltage Directive: 2006/95/EC
• EMC Guidelines: 2004/108/EC
Devices used in combination with this drive must also be CE certified and display the CE mark. When using drives
displaying the CE mark in combination with other devices, it is ultimately the responsibility of the user to ensure
compliance with CE standards. After setting up the device, verify that conditions meet European standards.
◆ CE Low Voltage Directive Compliance
This drive has been tested according to European standard IEC/EN 61800-5-1, and it fully complies with the Low
Voltage Directive.
To comply with the Low Voltage Directive, be sure to meet the following conditions when combining this drive with
other devices:
■
Area of Use
Do not use drives in areas with pollution higher than degree 2 and overvoltage category 3 in accordance with IEC/EN
664.
■
Installing Fuses on the Input Side
Always install input fuses. Select fuses according to Table D.1.
Table D.1 Recommended Input Fuse Selection
Model
CIMR-E
Fuse Type (Rated Voltage: 500 Vac)
Manufacturer: Bussmann
Model Fuse Ampere Rating (A)
Three-Phase 200 V Class
2A0004 FWH-70B 70
2A0006 FWH-70B 70
2A0008 FWH-70B 70
2A0010 FWH-70B 70
2A0012 FWH-70B 70
2A0018 FWH-90B 90
2A0021 FWH-90B 90
2A0030 FWH-100B 100
2A0040 FWH-200B 200
2A0056 FWH-200B 200
2A0069 FWH-200B 200
2A0081 FWH-300A 300
2A0110 FWH-300A 300
2A0138 FWH-350A 350
2A0169 FWH-400A 400
2A0211 FWH-400A 400
2A0250 FWH-600A 600
2A0312 FWH-700A 700
2A0360 FWH-800A 800
2A0415 FWH-1000A 1000
