D.2 European Standards
Standards Compliance
D
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 441
■ Guarding Against Harmful Materials
When installing IP00 enclosure drives, use an enclosure that prevents foreign material from entering the drive from
above or below.
■
Grounding
The drive is designed to be used in T-N (grounded neutral point) networks. If installing the drive in other types of
grounded systems, contact your Yaskawa representative for instructions.
◆ EMC Guidelines Compliance
This drive is tested according to European standards IEC/EN 61800-3: 2004, and complies with the EMC guidelines.
■
EMC Filter Installation
The following conditions must be met to ensure continued compliance with guidelines. Refer to EMC Filters on
page 444 for EMC filter selection.
Installation Method
Verify the following installation conditions to ensure that other devices and machinery used in combination with this
drive also comply with EMC guidelines.
1.
Install an EMC noise filter to the input side specified by Yaskawa for compliance with European standards.
2. Place the drive and EMC noise filter in the same enclosure.
3. Use braided shield cable for the drive and motor wiring, or run the wiring through a metal conduit.
4. Keep wiring as short as possible. Ground the shield on both the drive side and the motor side.
Three-Phase 400 V Class
4A0002 FWH-40B 40
4A0004 FWH-50B 50
4A0005 FWH-70B 70
4A0007 FWH-70B 70
4A0009 FWH-90B 90
4A0011 FWH-90B 90
4A0018 FWH-80B 80
4A0023 FWH-100B 100
4A0031 FWH-125B 125
4A0038 FWH-200B 200
4A0044 FWH-250A 250
4A0058 FWH-250A 250
4A0072 FWH-250A 250
4A0088 FWH-250A 250
4A0103 FWH-250A 250
4A0139 FWH-350A 350
4A0165 FWH-400A 400
4A0208 FWH-500A 500
4A0250 FWH-600A 600
4A0296 FWH-700A 700
4A0362 FWH-800A 800
4A0414 FWH-800A 800
4A0515 FWH-1000A 1000
4A0675 FWH-1200A 1200
4A0930 FWH-1200A 1200
4A1200 FWH-1600A 1600
Model
CIMR-E
Fuse Type (Rated Voltage: 500 Vac)
Manufacturer: Bussmann
Model Fuse Ampere Rating (A)
SIEP_C710616_35.book 441 ページ ２０１５年１１月３０日 月曜日 午後２時２分
