7.4 Cooling Fan and Circulation Fan
Periodic Inspection & Maintenance
7
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 303
7.4 Cooling Fan and Circulation Fan
NOTICE: Follow cooling fan replacement instructions. The cooling fan cannot operate properly when installed incorrectly and could
seriously damage the drive. To ensure maximum useful product life, replace all cooling fans when performing maintenance.
Contact your Yaskawa representative or the nearest Yaskawa sales office to order replacement cooling fans as required.
For drives with multiple cooling fans, replace all the fans when performing maintenance to ensure maximum product
performance life.
◆ Number of Fan
◆ Cooling Fan Component Names
WARNING! Electrical Shock Hazard. Do not connect or disconnect wiring while the power is on. Failure to comply can result in serious
personal injury. Before servicing the drive, disconnect all power to the equipment. The internal capacitor remains charged even after
the power supply is turned off. After shutting off the power, wait for at least the amount of time specified on the drive before touching
any components.
CAUTION! Burn Hazard. Do not touch a hot drive heatsink. Failure to comply could result in minor or moderate injury. Shut off the
power to the drive when replacing the cooling fan. To prevent burns, wait at least 15 minutes and ensure the heatsink has cooled
down.
Three-Phase 200 V Class Three-Phase 400 V Class
Model
CIMR-E
Cooling Fan Circulation Fan Page
Model
CIMR-E
Cooling Fan Circulation Fan
Control Board
Cooling Fan
Page
2A0004 – – – 4A0002 – – – –
2A0006 – – – 4A0004 – – – –
2A0008 – – – 4A0005 – – – –
2A0010 – – – 4A0007 1 – –
305
2A0012 – – – 4A0009 1 – –
2A0018 1 –
305
4A0011 1 – –
2A0021 1 – 4A0018 2 – –
2A0030 2 – 4A0023 2 – –
2A0040 2 – 4A0031 2 – –
2A0056 2 – 4A0038 2 – –
2A0069 2 – 4A0044 2 – –
2A0081 2 – 4A0058 2 – –
307
2A0110 2 –
307
4A0072 2 – –
2A0138 2 – 4A0088 2 – –
309
2A0169 2 –
311
4A0103 2 – –
2A0211 2 – 4A0139 2 – –
311
2A0250 2 – 4A0165 2 – –
2A0312 2 – 4A0208 2 – –
2A0360 3 1 4A0250 3 – –
2A0415 3 1 4A0296 3 – –
-–––4A0362 3 1 –
-–––4A0414 3 1 – 315
-–––4A0515 3 2 2
317
-–––4A0675 3 2 2
-–––4A0930 6 4 4
320
-–––4A1200 6 4 4
