1.2 General Description
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 27
1.2 General Description
◆ E1000 Model Selection
Table 1.1 gives a reference for drive selection depending on the motor power.
Note: The models and capacities in shown here are based on standard settings and operation conditions. Derating is required for higher
carrier frequencies and higher ambient temperatures.
Table 1.1 E1000 Models
Note: Current derating is required when setting the carrier frequency higher. Refer to Carrier Frequency Derating on page 354 for
details.
Motor Power
(kW)
Three-Phase 200 V Class Three-Phase 400 V Class
Model CIMR-E Rated Output Current (A) Model CIMR-E Rated Output Current (A)
0.75 2A0004 3.5 4A0002 2.1
1.1 2A0006 6 – –
1.5 2A0008 8 4A0004 4.1
2.2 2A0010 9.6 4A0005 5.4
3.0 2A0012 12 4A0007 6.9
3.7 2A0018 17.5 4A0009 8.8
5.5 2A0021 21 4A0011 11.1
7.5 2A0030 30 4A0018 17.5
11 2A0040 40 4A0023 23
15 2A0056 56 4A0031 31
18.5 2A0069 69 4A0038 38
22 2A0081 81 4A0044 44
30 2A0110 110 4A0058 58
37 2A0138 138 4A0072 72
45 2A0169 169 4A0088 88
55 2A0211 211 4A0103 103
75 2A0250 250 4A0139 139
90 2A0312 312 4A0165 165
110
2A0360 360 4A0208 208
2A0415 415 – –
132 – – 4A0250 250
160 – – 4A0296 296
185 – – 4A0362 362
220 – – 4A0414 414
250 – – 4A0515 515
355 – – 4A0675 675
500 – – 4A0930 930
630 – – 4A1200 1200
