B.6 Defaults by Drive Model Selection (o2-04)
400 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
B.6 Defaults by Drive Model Selection (o2-04)
The following tables show parameters and default settings that change with the drive model selection (o2-04).
Table B.6 200 V Class Drives Default Settings by Drive Model Selection
No. Name Unit Default Settings
Model CIMR-E – 2A0004 2A0006 2A0008 2A0010 2A0012 2A0018 2A0021
o2-04 Drive Model Selection Hex. 62 63 64 65 66 67 68
E2-11 Motor rated Output kW 0.75 1.1 1.5 2.2 3.0 3.7 5.5
b3-04 V/f Gain during Speed Search % 100 100 100 100 100 100 100
b3-06 Output Current 1 during Speed Search – 1 0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy Saving Coefficient Value – 223.7 196.6 169.4 156.8 136.4 122.9 94.75
C6-02Carrier Frequency Selection –7777777
E2-01 Motor Rated Current A 3.3 4.9 6.2 8.5 11.4 14 19.6
E2-02 Motor Rated Slip Hz 2.5 2.6 2.6 2.9 2.7 2.73 1.5
E2-03 Motor No-Load Current A 1.8 2.3 2.8 3 3.7 4.5 5.1
E2-05 Motor Line to Line Resistance Ω 5.156 3.577 1.997 1.601 1.034 0.771 0.399
E2-06 Motor Leakage Inductance % 13.8 18.5 18.5 18.4 19 19.6 18.2
E2-10 Motor Iron Loss for Torque Compensation W 26 38 53 77 91 112 172
E5-01 Motor Code Selection Hex. 1202 1203 FFFF 1205 1206 FFFF 1208
L2-02 Momentary Power Loss Ride-Thru Time s 0.1 0.2 0.3 0.3 0.5 1 1
L2-03 Momentary Power Loss Minimum Baseblock Time s 0.3 0.4 0.4 0.5 0.5 0.6 0.7
L2-04 Momentary Power Loss Voltage Recovery Time s 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L3-24 Motor Acceleration Time for Inertia Calculations s 0.142 0.142 0.166 0.145 0.145 0.154 0.168
L8-02 Overheat Alarm Level °C 115 115 115 115 125 110 110
L8-35Installation Method Selection –2222222
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10
No. Name Unit Default Settings
Model CIMR-E – 2A0030 2A0040 2A0056 2A0069 2A0081 2A0110 2A0138
o2-04 Drive Model Selection Hex. 6A 6B 6D 6E 6F 70 72
E2-11 Motor rated Output kW 7.5 11 15 18.5 22 30 37
b3-04 V/f Gain during Speed Search % 100 100 100 100 100 80 80
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy Saving Coefficient Value – 72.69 70.44 63.13 57.87 51.79 46.27 38.16
C6-02Carrier Frequency Selection –7777777
E2-01 Motor Rated Current A 26.6 39.7 53 65.8 77.2 105 131
E2-02 Motor Rated Slip Hz 1.3 1.7 1.6 1.67 1.7 1.8 1.33
E2-03 Motor No-Load Current A 8 11.2 15.2 15.7 18.5 21.9 38.2
E2-05 Motor Line to Line Resistance Ω 0.288 0.23 0.138 0.101 0.079 0.064 0.039
E2-06 Motor Leakage Inductance % 15.5 19.5 17.2 15.7 19.5 20.8 18.8
E2-10 Motor Iron Loss for Torque Compensation W 262 245 272 505 538 699 823
E5-01 Motor Code Selection Hex. 120A 120B 120D 120E 120F 1210 1212
L2-02Momentary Power Loss Ride-Thru Time s1122222
L2-03 Momentary Power Loss Minimum Baseblock Time s 0.8 0.9 1 1 1 1.1 1.1
L2-04 Momentary Power Loss Voltage Recovery Time s 0.3 0.3 0.6 0.6 0.6 0.6 0.6
L3-24 Motor Acceleration Time for Inertia Calculations s 0.175 0.265 0.244 0.317 0.355 0.323 0.32
L8-02 Overheat Alarm Level °C 120 125 120 120 125 130 130
L8-35Installation Method Selection –2222200
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10
