B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 373
◆ H Parameters: Multi-Function Terminals
H parameters assign functions to the multi-function input and output terminals.
■
H1: Multi-Function Digital Inputs
No.(Addr.) Name Description Setting Page
H1-01
(438H)
<31> Value in parenthesis is the default setting when a 3-wire initialization is performed (A1-03 = 3330).
Multi-Function Digital Input
Terminal S1 Function Selection
Assigns a function to the multi-function digital inputs.
Refer to H1 Multi-Function Digital Input Selections on page 373 for a description of setting
values.
Note: Unused terminals should be set to F.
Default: 40 (F)
<31>
Min: 1
Max: 9F
181
H1-02
(439H)
Multi-Function Digital Input
Terminal S2 Function Selection
Default: 41 (F)
<31>
Min: 1
Max: 9F
181
H1-03
(400H)
Multi-Function Digital Input
Terminal S3 Function Selection
Default: 24
Min: 0
Max: 9F
181
H1-04
(401H)
Multi-Function Digital Input
Terminal S4 Function Selection
Default: 14
Min: 0
Max: 9F
181
H1-05
(402H)
Multi-Function Digital Input
Terminal S5 Function Selection
Default: 3(0)
<31>
Min: 0
Max: 9F
181
H1-06
(403H)
Multi-Function Digital Input
Terminal S6 Function Selection
Default: 4(3)
<31>
Min: 0
Max: 9F
181
H1-07
(404H)
Multi-Function Digital Input
Terminal S7 Function Selection
Default: 6(4)
<31>
Min: 0
Max: 9F
181
H1-08
(405H)
Multi-Function Digital Input
Terminal S8 Function Selection
Default: 8
Min: 0
Max: 9F
181
H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description Page
0 3-wire Sequence
Closed: Reverse rotation (only if the drive is set up for 3-wire sequence)
Terminals S1 and S2 are automatically set up for the Run command and Stop command.
182
1 LOCAL/REMOTE Selection
Open: REMOTE (parameter settings determine the source of the frequency Reference 1 or 2 (b1-01, b1-02 or b1-
15, b1-16)
Closed: LOCAL, digital operator is run and reference source
182
2 External Reference 1/2 Selection
Open: Run command and frequency reference source 1 (determined by b1-01 and b1-02)
Closed: Run command and frequency reference source 2 (determined by b1-15 and b1-16)
183
3 Multi-Step Speed Reference 1
When input terminals are set to Multi-Step Speed References 1 through 3, switching combinations of those
terminals will create a multi-step speed sequence using the frequency references set in d1-01 through d1-04.
183
4 Multi-Step Speed Reference 2
6 Jog Reference Selection
Closed: Jog frequency reference (d1-17) selected. Jog has priority over all other reference sources.
183
7 Accel/Decel Time Selection 1
Used to switch between accel/decel time 1 (set in C1-01, C1-02) and accel/decel time 2 (set in C1-03, C1-04).
183
8 Baseblock Command (N.O.)
Closed: No drive output
183
9 Baseblock Command (N.C.)
Open: No drive output
183
A Accel/Decel Ramp Hold
Open: Accel/decel is not held
Closed: The drive pauses during acceleration or deceleration and maintains the output frequency.
183
B Drive Overheat Alarm (oH2)
Closed: Closes when an oH2 alarm occurs
183
C Analog Terminal Input Selection
Open: Function assigned by H3-14 is disabled.
Closed: Function assigned by H3-14 is enabled.
184
All Modes
SIEP_C710616_35.book 373 ページ ２０１５年１１月３０日 月曜日 午後２時２分
