YASKAWA E1000 User Manual

5.6 F: Option Settings
Parameter Details
5
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 179
5.6 F: Option Settings
◆ F6: Communication Option Card
These parameters are to configure communication option cards and communication fault detection methods.
Some parameters apply to all communication option cards, while some parameters are used only for certain network
options.
■
F6-01: Communications Error Operation Selection
Determines drive operation if a communication error occurs.
Setting 0: Ramp to stop (uses the deceleration time set to C1-02)
Setting 1: Coast to stop
Setting 2: Fast Stop (uses the Fast Stop time set to C1-09)
Setting 3: Alarm only (continue operation)
■ F6-02: External Fault from Comm. Option Detection Selection
Determines the detection method of an external fault initiated by a communication option (EF0).
Setting 0: Always detected
Setting 1: Detection during run only
■ F6-03: External Fault from Comm. Option Operation Selection
Determines the operation when an external fault is initiated by a communication option (EF0).
Setting 0: Ramp to stop
Setting 1: Coast to stop
Setting 2: Fast Stop
Setting 3: Alarm only (continue operation)
■ F6-07: Multi-Step Speed Enable/Disable when NetRef/ComRef is Selected
Selects how multi-step speed inputs are treated when the NetRef command is set.
Setting 0: Multi-step speed operation disabled
If the NetRef command is selected, multi-step speed input frequency references are disabled (like Yaskawa E7 drives).
Parameter
Communication Protocol
CC-Link <1> MECHATROLINK-II <1> PROFIBUS-DP <1> CANopen <1> DeviceNet <1>
F6-01 to F6-03 to F6-08 
<1> Under development

F6-04, -10, -11, -14  ––––
F6-20 to F6-26 –  –––
F6-30 to F6-32 – –  ––
F6-35 to F6-36 – – –  –
F6-50 to F6-63 ––––
No. Parameter Name Setting Range Default
F6-01 Communications Error Operation Selection 0 to 3 1
No. Parameter Name Setting Range Default
F6-02 External Fault from Comm. Option Detection Selection 0 or 1 0
No. Parameter Name Setting Range Default
F6-03 External Fault from Comm. Option Operation Selection 0 to 3 1
No. Parameter Name Setting Range Default
F6-07 NetRef/ComRef Function Selection 0, 1 0
SIEP_C710616_35.book 179 ページ ２０１５年１１月３０日 月曜日 午後２時２分
