1.5 Component Names
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 33
Receiving
1
IP00 Enclosure
Three-Phase AC200 V CIMR-E2A0110A, 0138A
Three-Phase AC400 V CIMR-E4A0058A to 0103A
Figure 1.2
Figure 1.3 Exploded View of IP00 Enclosure Components (CIMR-E2A0110A)
A Fan cover G Front cover
B Cooling fan H USB port (type-B)
C Mounting hole I Front cover screw
D Heatsink J Digital operator
E Optional 24 V DC power
supply connector cover
K Drive Cover
F Terminal board L Terminal cover
A
B
C
D
E
F
G
H
I
J
K
L
YEC_TMonly
SIEP_C710616_35.book 33 ペー 2015年11月30日 月曜日 午後2時2
